The Emerson VE4001S2T2B4 with KJ4001X1-CJ1 termination assembly is a DeltaV Series 2 discrete input solution designed for high-density digital signal acquisition in demanding process automation environments. This configuration is widely used for monitoring field devices such as limit switches, pushbuttons, relay contacts, alarm circuits, and equipment status signals.
Featuring a 32-channel architecture, the module helps reduce cabinet space requirements while maintaining excellent signal integrity, system reliability, and diagnostic capabilities. It is particularly suitable for large-scale process facilities requiring centralized monitoring of numerous digital inputs.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Model | VE4001S2T2B4 |
| Termination Block | KJ4001X1-CJ1 |
| Product Type | Discrete Input Module |
| System Platform | DeltaV M-Series / Series 2 |
| Input Channels | 32 Channels |
| Input Signal Type | 24 VDC Dry Contact |
| Voltage Range | 19.2–28.8 VDC |
| Current Consumption | Approx. 2.5 mA per channel |
| Response Time | 1 ms Typical |
| Isolation | Channel-to-Chassis Isolation |
| Diagnostics | Built-in Channel Monitoring |
| Termination Type | 32-Channel Terminal Block |
| Maximum Terminal Block Rating | 30 VDC, 1 A |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5%–95% Non-Condensing |
| Mounting Method | DeltaV Carrier Mounted |
Physical Dimensions & Weight
| Parameter | Specification |
|---|---|
| Dimensions (L × W × H) | 220 × 120 × 60 mm |
| Weight | Approx. 0.50 kg |
