The Emerson VE4002S1T1B3 is a DeltaV Series 2 discrete output module designed for stable and accurate control of industrial field devices. It is commonly used to drive actuators such as solenoid valves, relay coils, motor starters, alarms, and other ON/OFF control elements in process automation systems.
This module belongs to Emerson’s high-integrity output family and is engineered for continuous operation in harsh industrial environments where reliability, electrical isolation, and consistent switching performance are essential.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Model | VE4002S1T1B3 |
| Product Type | Discrete Output Module (DO) |
| System Platform | DeltaV Series 2 |
| Output Channels | 8 channels |
| Output Type | 24 V DC digital output |
| Output Configuration | Isolated output channels |
| Load Type | Relay / solenoid / actuator control |
| Output Voltage | 24 V DC nominal |
| Load Capacity | Up to 1 A per channel (typical industrial range) |
| Switching Type | Electronic switching (high-side driving architecture) |
| Isolation | Channel-to-system galvanic isolation |
| Diagnostics | Channel status + fault detection |
| Protection | Overcurrent and short-circuit protection (system level) |
| Mounting Method | DeltaV I/O carrier mounted |
| Wiring Interface | Standard termination block system |
| Operating Temperature | -40°C to +70°C |
| Humidity Range | 5%–95% non-condensing |
| EMC Protection | Industrial noise immunity design |
Physical Dimensions & Weight
| Parameter | Specification |
|---|---|
| Dimensions (L × W × H) | 140 × 100 × 75 mm |
| Length × Width × Height | Carrier-mounted standard format |
| Weight | Approx. 0.25–0.60 kg |
