The Emerson VE4002S1T2B3 (KJ3202X1-BA1 + KJ4001X1-CE1) is a DeltaV Series 2 discrete output module designed for precise and stable control of field actuators in industrial automation systems. It is commonly used to drive solenoids, relay coils, motor starters, valves, and alarm devices requiring fast and reliable ON/OFF switching.
This configuration combines the KJ3202X1-BA1 output card with the KJ4001X1-CE1 mass termination block, enabling structured wiring, simplified installation, and improved maintenance efficiency in large-scale distributed control systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Model | VE4002S1T2B3 |
| Module Part No. | KJ3202X1-BA1 |
| Termination Block | KJ4001X1-CE1 |
| Product Type | Discrete Output Module (DO) |
| System Platform | DeltaV Series 2 I/O |
| Output Channels | 8 channels |
| Output Type | 24 V DC high-side digital output |
| Field Voltage | 24 V DC nominal |
| Load Capacity | Up to 1 A per channel (typical industrial load range) |
| Output Function | ON/OFF actuator control |
| Switching Type | Electronic high-side switching |
| Isolation | Channel-to-system galvanic isolation |
| Diagnostics | Channel status monitoring & fault detection |
| Protection | Short-circuit and overcurrent protection (system design level) |
| Wiring Interface | 16-pin mass termination block (KJ4001X1-CE1) |
| Mounting Method | DeltaV I/O carrier mounted |
| Operating Temperature | -40°C to +70°C |
| Humidity Range | 5%–95% non-condensing |
| EMC Protection | Industrial-grade noise immunity design |
Physical Dimensions & Weight
| Parameter | Specification |
|---|---|
| Dimensions (L × W × H) | 140 × 100 × 75 mm |
| Length × Width × Height | Carrier-mounted standard structure |
| Weight | Approx. 0.21–0.40 kg |
