Emerson KL3005X1-LS1 Isolated Digital Input Module
Emerson KL3005X1-LS1 Isolated Digital Input Module
0.0
Points
Brand:Emerson Module Item No.:KL3005X1-LS1 Product Origin:USA Product Dimensions:121 x 157 x 30 mm Product Weight:0.8 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Emerson KL3005X1-LS1 Isolated Digital Input Module is a key component of the DeltaV CHARM-based I/O system, designed to reliably capture discrete field signals in industrial automation environments. It converts external ON/OFF device states into stable digital signals for use in process control and monitoring.
Technical Specifications
Parameter
Specification
Product Model
KL3005X1-LS1
Manufacturer
Emerson
Series
DeltaV CHARM
Product Type
Isolated Digital Input Module
Input Signal Type
24 VDC Discrete Input
Function
Field signal acquisition and isolation
Application
Industrial automation and process control
Dimensions
121 × 157 × 30 mm
Weight
0.8 kg
Recommended Related Models
Model
Product Name
KL3002X1-LS1
High-side Discrete Output Module
KL3003X1-LS1
Digital Input Module Variant
VE4003S2B1
Analog Input Module
VE4033S2B1
Analog Output Module
Popular Related Models
Model
Product Name
KJ3222X1-BA1
Analog Input Module
KJ4010X1-BG1
Communication Module
VE3008
DeltaV Controller Module
KJ2003X1-BA1
Network Interface Module
Applications
• Used in Emerson DeltaV distributed control systems (DCS) for monitoring discrete field device status signals.
• Applied in oil & gas plants, chemical processing units, refineries, and power generation facilities for real-time on/off signal acquisition.
• Suitable for industrial automation systems requiring 24 VDC isolated digital input processing.
• Integrated into control cabinets to interface with switches, relays, proximity sensors, and contact outputs.
• Supports critical process monitoring where reliable signal isolation and noise immunity are required.
Key Advantages
• Provides galvanic isolation to protect control systems from electrical noise and ground loops.
• Ensures stable and accurate detection of discrete ON/OFF field signals.
• Designed for seamless integration within Emerson DeltaV CHARM architecture.
• High immunity to industrial electromagnetic interference improves system reliability.
• Robust construction supports long-term operation in harsh process environments.
Technical FAQs
1. What is the main function of the KL3005X1-LS1 module?
It acquires and processes isolated 24 VDC digital input signals from field devices.
2. What system is it used with?
It is designed for Emerson DeltaV distributed control systems.
3. What type of signals does it handle?
It handles discrete ON/OFF signals typically at 24 VDC.
4. What does “isolated input” mean?
It means each input is electrically separated to prevent interference and ground loop issues.
5. What devices can be connected?
Switches, relays, limit switches, and proximity sensors.
6. Does it perform control logic?
No, it only reads field input states and sends them to the control system.
7. Is it suitable for harsh environments?
Yes, it is designed for industrial temperature, vibration, and electrical noise conditions.
8. Does it require field calibration?
No calibration is required for digital input modules.
9. What happens if a channel fails?
The system will lose status monitoring for the affected input point.
10. Why is isolation important in digital input modules?
It improves safety, protects equipment, and prevents signal interference.
