The Emerson VE4002S2T1B2 is a DeltaV Series 2 discrete output module designed for stable and precise ON/OFF control of field devices in industrial automation systems. It is commonly used to drive solenoid valves, relay coils, motor starters, alarm indicators, and other discrete actuators in continuous process environments.
This module is engineered for harsh industrial conditions where reliability, electrical isolation, and consistent switching performance are critical for safe and efficient plant operation.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Model | VE4002S2T1B2 |
| Product Type | Discrete Output Module (DO) |
| System Platform | DeltaV Series 2 I/O |
| Output Channels | 8 channels |
| Output Type | 24 V AC/DC digital output (high-side switching) |
| Field Voltage Range | 24 V DC nominal (industrial range supported) |
| Load Type | Relay / solenoid / actuator control |
| Output Current | ~0.5–1 A per channel (typical application range) |
| Switching Type | Electronic high-side switching |
| Isolation | Channel-to-system galvanic isolation |
| Diagnostics | Channel status, open-load and fault detection |
| Protection | Short-circuit and overcurrent protection (system-level) |
| Wiring Interface | DeltaV termination system with carrier mounting |
| Mounting Method | DeltaV I/O carrier mounted |
| Operating Temperature | -40°C to +70°C |
| Humidity Range | 5%–95% non-condensing |
| EMC Protection | Industrial-grade noise immunity design |
Physical Dimensions & Weight
| Parameter | Specification |
|---|---|
| Dimensions (L × W × H) | 105 × 125 × 42 mm |
| Length × Width × Height | Compact DeltaV standard module format |
| Weight | Approx. 0.25–0.60 kg |
