Brand:Emerson Module Item No.:KL4501X1-BA1 Product Origin:USA Product Dimensions:22 x 104 x 106 mm Product Weight:0.05 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Emerson KL4501X1-BA1 CHARM Address Plug is a critical component of the DeltaV Electronic Marshalling system, designed to ensure correct identification and addressing of CHARM I/O modules. It plays a key role in organizing modular I/O architecture by assigning proper addresses to each installed module.
Technical Specifications
Parameter
Specification
Product Model
KL4501X1-BA1
Manufacturer
Emerson
Series
DeltaV CHARM
Product Type
CHARM Address Plug
Function
Module addressing & identification
System Compatibility
DeltaV Electronic Marshalling
Installation
CHARM base plate system
Dimensions
22 × 104 × 106 mm
Weight
0.05 kg
Recommended Related Models
Model
Product Name
KL4210X1-BA1
IS CHARM Base Plate
KL3031X1-BA1
RTD/Resistance Input Module
KL3005X1-LS1
Isolated Digital Input Module
KL3002X1-LS1
High-side Discrete Output Module
Popular Related Models
Model
Product Name
KJ3222X1-BA1
DeltaV Analog Input Module
KJ4010X1-BG1
Communication Interface Module
VE3008
DeltaV Controller Module
VE4033S2B1
Analog Output Module
Applications
• Used in Emerson DeltaV Electronic Marshalling systems to provide correct addressing for CHARM I/O modules.
• Applied in oil & gas plants, chemical processing facilities, refineries, and power generation systems for distributed control architectures.
• Suitable for hazardous and industrial environments where reliable module identification is required.
• Integrated into CHARM base plate assemblies to ensure proper signal routing and I/O configuration.
• Supports modular automation systems by enabling consistent and error-free CHARM channel assignment.
Key Advantages
• Ensures accurate addressing of CHARM modules to prevent wiring and configuration errors.
• Mechanical keying design reduces risk of incorrect module installation.
• Supports reliable operation in harsh industrial environments with vibration and temperature variations.
• Fully compatible with Emerson DeltaV Electronic Marshalling architecture.
• Maintenance-free design with long-term stable performance.
Technical FAQs
1. What is the main function of the KL4501X1-BA1?
It provides addressing for CHARM I/O modules within DeltaV Electronic Marshalling systems.
2. What system is it used with?
It is used with Emerson DeltaV CHARM-based I/O architecture.
3. Does it process signals?
No, it only handles module addressing and identification.
4. Why is addressing important in CHARM systems?
It ensures each I/O module is correctly identified and mapped in the control system.
5. Can it be replaced individually?
Yes, it can be replaced without affecting other system components if properly de-energized.
6. Does it require calibration?
No, it is a passive mechanical/electrical identification component.
7. What happens if it is missing or incorrect?
The CHARM module may not be recognized or may be incorrectly mapped.
8. Is it used in hazardous environments?
Yes, it is designed for industrial and potentially hazardous applications.
9. Does it affect signal quality?
Indirectly, yes—correct addressing ensures proper system configuration and data integrity.
10. Why is it essential in DeltaV systems?
It guarantees correct CHARM module positioning and reliable system organization.
