Emerson VE4003S2B4 KJ3222X1-BA1 + KJ4001X1-CE1 Analog Input Module
Emerson VE4003S2B4 KJ3222X1-BA1 + KJ4001X1-CE1 Analog Input Module
0.0
Points
Brand:Emerson Module Item No.:Emerson VE4003S2B4 KJ3222X1-BA1 + KJ4001X1-CE1 Product Origin:USA Product Dimensions:160 × 130 × 40 mm Product Weight:0.50 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Emerson VE4003S2B4 (KJ3222X1-BA1 + KJ4001X1-CE1) is a high-performance analog input module designed for the Emerson DeltaV Series 2 Distributed Control System (DCS). It provides accurate acquisition of 4–20 mA analog signals from field instruments such as pressure transmitters, temperature transmitters, flow meters, and level sensors, while supporting HART communication for advanced diagnostics and device management.
The module combines the KJ3222X1-BA1 Analog Input Card with the KJ4001X1-CE1 Mass Termination Block, offering simplified wiring, reliable signal transmission, and efficient installation in industrial automation applications.
Technical Specifications
Parameter
Specification
Manufacturer
Emerson
Model
VE4003S2B4
I/O Card
KJ3222X1-BA1
Termination Block
KJ4001X1-CE1
Product Type
Analog Input Module (AI)
System Platform
DeltaV Series 2 I/O
Input Channels
8 Channels
Input Signal
4–20 mA Current Input
HART Communication
Supported
A/D Resolution
16-bit
Measurement Accuracy
±0.1% Full Scale (Typical)
Isolation
Channel-to-System Galvanic Isolation
Diagnostics
Open Loop Detection, Transmitter Diagnostics, HART Status Monitoring
Wiring Method
Mass Termination
Mounting Method
DeltaV Carrier Mounted
Operating Temperature
-40°C to +70°C
Relative Humidity
5%–95% Non-Condensing
EMC Compliance
Industrial Grade EMC Protection
Physical Dimensions & Weight
Parameter
Specification
Dimensions (L × W × H)
160 × 130 × 40 mm
Weight
Approx. 0.50 kg
Applications
Oil & Gas
Monitoring of pressure, flow, level, and temperature transmitters in upstream and downstream facilities.
Chemical & Petrochemical
Acquisition of critical process variables for reactors, pipelines, and storage systems.
Power Generation
Used in turbine control, boiler instrumentation, and auxiliary process monitoring.
Water & Wastewater Treatment
Provides reliable analog signal acquisition from pumps, tanks, and treatment equipment.
Manufacturing
Supports automated production systems requiring continuous process measurement.
Advantages
High-accuracy 4–20 mA signal acquisition
Full HART communication support
Mass termination design for faster installation
Advanced diagnostic capabilities
Excellent electrical isolation
Seamless integration with DeltaV Series 2 systems
Industrial-grade reliability for 24/7 operation
Technical FAQs
1. What is the VE4003S2B4 used for?
It is used for acquiring analog process signals from field instruments within DeltaV control systems.
2. How many input channels are available?
The module provides 8 analog input channels.
3. Does it support HART communication?
Yes, full HART communication support is included.
4. What signal types can be connected?
Standard 4–20 mA analog current loop signals.
5. What is the purpose of the KJ4001X1-CE1?
It is a mass termination block that simplifies field wiring and installation.
6. Is electrical isolation provided?
Yes, channel-to-system galvanic isolation is included.
7. Which control platform is it designed for?
Emerson DeltaV Series 2 Distributed Control System (DCS).
8. What are the dimensions?
160 × 130 × 40 mm (L × W × H)
9. What is the weight?
Approximately 0.50 kg
10. Why is this module widely used?
Because it delivers accurate analog signal acquisition, HART communication support, advanced diagnostics, and reliable long-term performance in critical industrial automation applications.
