Introduction

The GE Fanuc IS200TDBSH2A Discrete Input/Output Terminal Block provides reliable and secure connectivity for digital signals in industrial automation systems. Its modular design and industrial-grade construction make it ideal for IS200 PLC systems requiring precise, fault-tolerant discrete I/O integration. By combining durability, diagnostics, and flexible rack integration, this terminal block ensures optimal system performance and reliability.

Technical Specifications

Specification	Details
Module Type	Discrete Input/Output Terminal Block
Number of Connections	32 Discrete Inputs/Outputs
Supported Voltage	24V DC nominal
Redundancy	Supports dual-redundant configurations
Operating Temperature	-20°C to 70°C (-4°F to 158°F)
Weight	1.1 kg
Dimensions	280 x 150 x 40 mm
Connectivity	Screw terminal blocks
Certifications	CE Compliant

Recommended Related Models

GE Fanuc IS200CPU Central Processing Unit
IS200EXC Excitation Control Module
IS200EPSMG2A Exciter Power Module

Popular Related Models

GE Fanuc IS200TDBSH1A Discrete I/O Terminal Block
IS200PSU Power Supply Module
IS200RTU Remote Terminal Unit

Applications

The GE Fanuc IS200TDBSH2A Discrete Input/Output Terminal Block is designed for efficient and reliable connection of digital signals in industrial automation systems. Typical applications include:

Factory automation systems with discrete I/O requirements
Process control systems in chemical, petrochemical, and power plants
Integration with GE Fanuc IS200 PLCs for I/O expansion
Redundant control architectures where secure I/O connections are critical
Industrial installations requiring reliable signal routing and monitoring

Advantages

High Reliability: Maintains secure connections in harsh industrial environments.
Modular Design: Easily integrates into IS200 rack systems for flexible I/O expansion.
Diagnostic Transparency: LED indicators provide immediate feedback on I/O status.
Industrial Durability: Resistant to vibration, temperature extremes, and electrical noise.
Simplified Maintenance: Clear labeling and robust design allow easy inspection and replacement.

Technical FAQs

What is the function of the IS200TDBSH2A?
- Provides centralized terminal connections for discrete input and output signals.
How many I/O connections does it support?
- Supports up to 32 discrete inputs or outputs per terminal block.
Is it compatible with redundant systems?
- Yes, it works in dual-redundant GE Fanuc IS200 configurations.
What voltage does it support?
- Standard 24V DC industrial discrete I/O signals.
Does it provide visual diagnostics?
- Yes, onboard LEDs indicate input/output activity and fault status.
Can it be used in high-vibration environments?
- Yes, industrial-grade design ensures reliable operation under vibration and electrical noise.
Is hot-swapping supported?
- Yes, modules can be replaced without shutting down the system in redundant setups.
What maintenance is required?
- Periodic inspection of terminal connections and LED status is recommended.
Does it comply with industrial safety standards?
- Yes, CE certified for industrial applications.
What type of connectors are used?
- Screw terminal blocks for secure and reliable wiring.
