The Bently Nevada 330103-06-14-20-01-00 is a 3300 XL 8 mm Proximity Probe Module designed for precise, non-contact measurement of shaft vibration, radial displacement, axial position, and rotor dynamic behavior in industrial rotating machinery.
This configuration combines a “06” compact probe body class, a 140 mm probe length option, a 2.0-meter integral cable, and configuration code 01, making it suitable for installations that require extended signal routing and deeper mechanical reach in complex machinery layouts.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model Number | 330103-06-14-20-01-00 |
| Product Type | 3300 XL 8 mm Proximity Probe Module |
| Measurement Technology | Eddy Current, Non-Contact |
| Probe Diameter | 8 mm |
| Probe Case Length | 06 (compact configuration class) |
| Probe Length Option | 140 mm |
| Integral Cable Length | 2.0 m |
| Connector Type | Miniature Coaxial ClickLoc™ Connector |
| Configuration Code | 01 |
| Thread Specification | M10 × 1 |
| Housing Material | Stainless Steel |
| Probe Tip Material | PPS (Polyphenylene Sulfide) |
| System Compatibility | Bently Nevada 3300 XL Proximitor® Systems |
Dimensions & Weight
| Item | Specification |
|---|---|
| Probe Body Length | ~60 mm (compact 06 class interpretation) |
| Cable Length | 2000 mm |
| Approximate Net Weight | 0.33 kg |
| Approximate Shipping Weight | 2.05 kg |
| Package Dimensions | 300 × 180 × 80 mm |
Designed for Extended Cabling and Deep Mechanical Access
The 330103-06-14-20-01-00 is optimized for industrial environments where both deep probe reach and longer cable routing are required. The 2.0-meter cable provides additional installation flexibility, allowing the probe to be mounted in high-temperature or high-vibration zones while keeping the connection point in a safer, more accessible location.
Its eddy-current sensing technology ensures stable, high-resolution measurement performance even under harsh operating conditions such as oil mist, humidity, vibration, and thermal cycling. The stainless-steel construction further enhances durability and long-term reliability.
Recommended Related Models
| Model | Description |
|---|---|
| 330103-06-14-10-01-00 | 1.0 m cable version |
| 330103-06-14-05-01-00 | 0.5 m cable version |
| 330103-06-13-20-01-00 | 130 mm probe version |
| 330103-06-15-20-01-00 | 150 mm extended version |
