Allen Bradley 22F-D018N104 PowerFlex 4M AC Drive

Applications

• Conveyor systems and material handling lines requiring stable motor speed regulation and smooth acceleration control.

• Pump and fan control systems in HVAC, water treatment, and light process industries.

• General industrial machinery such as mixers, extruders, and small production equipment.

• OEM equipment design where cost-effective motor control and compact installation are required.

• Retrofit projects replacing traditional contactor-based motor starters with VFD-based control.

• Light manufacturing automation systems requiring basic but reliable AC motor control.

Key Advantages

• Delivers reliable V/Hz motor control suitable for a wide range of standard industrial applications.

• Compact Frame C design enables easy installation in space-constrained control panels.

• Integrated RS-485 communication supports basic network integration with PLC systems.

• Built-in braking IGBT improves deceleration performance in dynamic load applications.

• Simple keypad interface reduces commissioning time and simplifies parameter setup.

• Cost-effective design makes it ideal for OEMs and large-scale deployments.

Technical FAQs

Q1: What is the rated power of the 22F-D018N104?
It supports approximately 7.5 kW (10 HP) motor applications.

Q2: What input voltage does this drive require?
It operates on 480V AC three-phase input.

Q3: Does it support communication with PLC systems?
Yes, it includes RS-485 communication capability.

Q4: What control method does it use?
It uses V/Hz control with slip compensation.

Q5: Is it suitable for pump and fan applications?
Yes, it is widely used in HVAC and pumping systems.

Q6: Does it include a braking function?
Yes, it includes a built-in brake IGBT for dynamic braking.

Q7: Can it be mounted on DIN rail?
Yes, A and B frame variants support DIN rail mounting.

Q8: Is it suitable for harsh environments?
It is IP20 rated, intended for installation inside control cabinets.

Q9: Can it operate at high ambient temperature?
Yes, up to around 50°C depending on installation conditions.

Q10: Is it programmable?
Yes, parameters can be configured via built-in keypad or software tools.
