Allen Bradley 5094-RTB3T Flex 5000 CJC Detachable Terminal Block
Allen Bradley 5094-RTB3T Flex 5000 CJC Detachable Terminal Block
0.0
Points
Brand:Allen Bradley PLC Item No.:5094-RTB3T Product Origin:USA Product Dimensions:94 x 53 x 76 mm Product Weight:0.202 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen-Bradley 5094-RTB3T FLEX 5000 CJC terminal block is a key component in Rockwell’s FLEX 5000 distributed I/O system. It provides a reliable and modular interface for field wiring connections, particularly in analog and thermocouple applications requiring temperature compensation accuracy.
Technical Specifications
Parameter
Specification
Model
5094-RTB3T
Series
FLEX 5000
Function
CJC Removable Terminal Block
Application
Analog / Thermocouple I/O systems
Embedded CJC
Yes (Cold Junction Compensation)
Terminal Type
Screw-type terminals
Conductor Type
Solid / stranded copper
Operating Voltage
10–32 V DC
Current Rating
Up to 100 mA
Channel Load
Up to 10 A pass-through capability
Dimensions
94 × 53 × 76 mm
Weight
0.202 kg
Recommended Related Models
Model
Product Name
5094-RTB3TS
FLEX 5000 Spring-Type CJC Terminal Block
5094-MB
FLEX 5000 I/O Mounting Base
5094-IB16
FLEX 5000 16-point Digital Input Module
5094-IF8
FLEX 5000 8-channel Analog Input Module
Popular Related Models
Model
Product Name
5094-OB16
FLEX 5000 16-point Digital Output Module
5094-AENTR
FLEX 5000 EtherNet/IP Adapter Module
5094-IA16
FLEX 5000 AC Input Module
5094-OF8
FLEX 5000 Analog Output Module
Applications
• FLEX 5000 analog input systems used in process automation requiring thermocouple and temperature signal conditioning.
• Industrial temperature monitoring systems in chemical, oil & gas, and power generation environments.
• Distributed I/O cabinets where removable terminal blocks simplify maintenance and wiring replacement.
• High-density control systems requiring reliable field-side signal termination for analog modules.
• Industrial automation panels using FLEX 5000 architecture for scalable I/O expansion.
• Machine-level process control systems requiring stable signal integrity under electrical noise conditions.
• Designed for FLEX 5000 architecture enabling seamless compatibility with Rockwell automation systems.
• Supports high-reliability analog signal termination with improved shielding and grounding capability.
• Reduces maintenance downtime through modular plug-in terminal structure.
Technical FAQs
Q1: What is the main function of the 5094-RTB3T?
It provides a removable field wiring interface for FLEX 5000 I/O modules with integrated CJC compensation.
Q2: What does CJC mean in this module?
CJC stands for Cold Junction Compensation used to improve thermocouple temperature accuracy.
Q3: Is this terminal block reusable?
Yes, it is designed for repeated installation and removal in FLEX 5000 systems.
Q4: What type of wiring does it support?
It supports solid and stranded copper conductors using screw-type terminals.
Q5: Is it used for digital or analog modules?
It is primarily used with analog and temperature measurement modules.
Q6: Can it be replaced without powering down the system?
Depending on system configuration, FLEX 5000 supports controlled replacement procedures.
Q7: Does it provide electrical isolation?
It supports system-level isolation depending on the connected I/O module.
Q8: What is its role in FLEX 5000 architecture?
It acts as the field wiring interface between sensors and I/O modules.
Q9: Is it compatible with all FLEX 5000 modules?
It is compatible with specific analog and thermocouple-related FLEX 5000 modules.
Q10: Why is it detachable?
To simplify maintenance, reduce downtime, and allow quick replacement of wiring assemblies.
