The Schneider AS-HDTA-200 Modicon Subrack is a primary 5-slot rack system designed for the Modicon TSX Compact PLC architecture. It serves as the mechanical and electrical backbone for CPU and I/O module installation, providing stable mounting, signal distribution, and system organization for industrial automation applications.
This subrack is widely used in distributed PLC systems where modular expansion and reliable hardware integration are required. It enables engineers to build scalable automation architectures by supporting multiple input/output modules in a structured and electrically stable environment.
Designed for industrial-grade applications, the AS-HDTA-200 ensures secure module alignment, stable backplane communication, and long-term operational reliability. It is commonly deployed in manufacturing systems, process control environments, and legacy Modicon installations where system continuity is critical.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Schneider Electric |
| Series | Modicon TSX Compact |
| Model | AS-HDTA-200 |
| Module Type | Primary Subrack / PLC Backplane |
| Slot Capacity | 5 Slots |
| System Role | CPU + I/O Module Mounting Base |
| Compatible System | Modicon 984 / TSX Compact PLC |
| Configuration | Linear / Expandable rack architecture |
| Function | Mechanical mounting + electrical backplane |
Physical Dimensions & Weight
| Parameter | Value |
|---|---|
| Size (L × W × H) | 212 × 142 × 24 mm |
| Weight | 0.20–1.36 kg (varies by configuration and installation condition) |
