The Bently Nevada 330180-X2-05 181634-01 Proximitor Sensor is part of the 3300 XL proximity transducer system used for continuous monitoring of vibration, shaft displacement, and rotor position in rotating machinery.
It works with proximity probes and extension cables to convert eddy current gap signals into stable analog voltage outputs. These signals are used by machinery protection and condition monitoring systems to support real-time diagnostics and predictive maintenance in turbines, compressors, pumps, and other critical rotating equipment.
The 3300 XL platform is widely used in industrial environments due to its high electromagnetic interference immunity, long-term stability, and compatibility with standardized machinery monitoring systems.
The 181634-01 modification code represents a configuration-specific variant within the 330180 series, typically related to assembly revision, system integration, or certification differences.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Bently Nevada |
| Series | 3300 XL |
| Model | 330180-X2-05 |
| Modification | 181634-01 |
| Type | Proximitor Sensor / Signal Conditioning Module |
| Measurement System | Eddy current non-contact transducer system |
| Function | Vibration / shaft position / displacement monitoring |
| Operating Voltage | 10–30 VDC |
| Output Signal | Linear analog voltage proportional to gap distance |
| System Compatibility | 3300 XL probe & extension cable system |
| Application | Machinery protection and condition monitoring |
Physical Dimensions & Weight
| Parameter | Value |
|---|---|
| Size (L × W × H) | 88 × 36 × 71 mm |
| Weight | 0.20–0.25 kg |
