Brand:Schneider PLC Item No.:Schneider ATS430D32S6 Product Origin:France Product Dimensions:130 × 169 × 273 mm Product Weight:2.9 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider ATS430D32S6 is part of the Altivar Soft Starter ATS430 series, designed for smooth starting and stopping of three-phase asynchronous motors. It combines torque control, advanced monitoring, and high-efficiency power electronics to improve system reliability and reduce mechanical stress in industrial applications.
Compared with traditional starting methods, it significantly reduces inrush current and helps extend the service life of motors, pumps, compressors, and conveyor systems. The ATS430 platform also focuses on energy efficiency, diagnostics, and long-term operational stability.
Technical Specifications
Item
Description
Manufacturer
Schneider Electric
Model
ATS430D32S6
Product Series
Altivar ATS430
Product Type
Soft Starter
Rated Current
32 A
Supply Voltage
208–600 VAC
Control Supply Voltage
110–230 VAC
Frequency
50/60 Hz
Motor Compatibility
Three-phase asynchronous motors
Control Method
Torque control + current limitation
Communication
Modbus (RJ45 interface)
Integrated Bypass
Yes
Protection Functions
Motor overload, phase loss, thermal protection
Standards
IEC/EN 60947-4-2 compliant design
Physical Dimensions & Weight
Parameter
Value
Dimensions (L × W × H)
130 × 169 × 273 mm
Weight
Approx. 2.9 kg
Recommended Related Models
Schneider ATS430C32S6 Soft Starter
Schneider ATS430D47S6 Soft Starter
Schneider ATS430D62S6 Soft Starter
Schneider ATS22 Series Soft Starters
Schneider Altivar ATV630 / ATV930 Drives
Schneider TeSys D Motor Contactors
Popular Schneider Automation Products
Altivar ATS430 Soft Starter Series
Altistart ATS22 Series
Altivar ATV600 / ATV900 Drive Series
Modicon M340 PLC System
Modicon M580 PLC System
TeSys Motor Control Systems
Applications
The ATS430D32S6 is widely used in industrial automation systems such as:
Water treatment plants
HVAC systems
Industrial pumping stations
Air compressors
Conveyor systems
Fans and blowers
Mixers and agitators
Mining and material handling equipment
Manufacturing production lines
Power distribution systems
Key Advantages
Smooth motor start and stop with torque control
Reduces mechanical shock and electrical stress
Improves motor and equipment lifespan
Integrated bypass reduces heat losses
Advanced monitoring and diagnostic capability
Compact panel-friendly installation design
High energy efficiency (optimized power control)
Reliable operation in industrial environments
Easy integration with PLC and automation systems
Cost-effective alternative to full variable speed drives
Technical FAQs
1. What is the Schneider ATS430D32S6 used for?
It is used for controlled starting and stopping of three-phase asynchronous motors.
2. What is the rated current?
The device is rated for 32 A motor applications.
3. What is the full size of the unit?
The dimensions are 130 × 169 × 273 mm (L × W × H).
4. What is the weight?
The unit weighs approximately 2.9 kg.
5. Does it support communication?
Yes, it supports Modbus communication via RJ45 interface.
6. What motors is it compatible with?
Three-phase squirrel-cage induction motors.
7. Does it include protection features?
Yes, including overload, phase loss, and thermal protection.
8. Where is it typically used?
In pumps, HVAC, compressors, conveyors, and industrial systems.
9. Does it include a bypass?
Yes, it has an integrated bypass function.
10. Why choose ATS430D32S6?
Because it offers reliable torque-controlled motor starting, energy efficiency, and strong integration into modern Schneider automation systems.
