Brand:Schneider PLC Item No.:ATS01N222QN Product Origin:France Product Dimensions:154 x 45 x 131 mm Product Weight:0.56 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The ATS01N222QN is part of the Schneider Electric Altistart 01 series, designed for simple and reliable soft motor starting. It provides controlled voltage ramp-up to reduce electrical stress on the supply system and mechanical stress on connected equipment.
Its compact structure and straightforward wiring make it suitable for OEM applications and industrial installations requiring stable motor control without complex configuration.
Technical Specifications
Parameter
Value
Product Series
Schneider Altistart 01
Model
ATS01N222QN
Device Type
Soft Starter
Rated Supply Voltage
380–415 V AC (3-phase)
Frequency
50/60 Hz
Rated Current
22 A
Motor Power Range
7.5 – 11 kW
Control Method
Voltage ramp start
Protection Class
IP20
Mounting Type
DIN rail / panel mounting
Operating Temperature
-10°C to +40°C
Storage Temperature
-25°C to +70°C
Dimensions (H × W × D)
154 × 45 × 131 mm
Weight
0.56 kg (1.23 lb)
Recommended Related Models
Schneider ATS01N212QN – 12A Soft Starter Module
Schneider ATS01N232QN – 32A Soft Starter Module
Schneider ATS22 Series Soft Starters
Schneider Altivar ATV310 Series Drives
Popular Related Models
ATS01N212QN Soft Starter Module
ATS01N222QN Soft Starter Module
ATS01N232QN Soft Starter Module
ATS48 Series Soft Starters
Applications
The Schneider ATS01N222QN Soft Starter is designed for controlled motor starting in industrial systems where reducing electrical surge and mechanical stress is required.
Typical applications include:
HVAC ventilation and air handling systems
Water pumping and wastewater treatment systems
Conveyor and light material handling systems
Compressors and refrigeration equipment
Agricultural irrigation pumping systems
Standard OEM industrial machinery
It improves system stability by enabling smooth motor acceleration and reducing stress on driven equipment.
Advantages
Compact design suitable for tight control cabinet installations
Smooth voltage ramp reduces mechanical impact during startup
Built-in bypass function improves operational efficiency
Reduces peak starting current on electrical networks
Helps extend motor and mechanical component lifespan
Simple setup with minimal configuration required
Stable operation in standard industrial environments
Designed according to Schneider Electric quality standards
Technical FAQs (10 Questions)
Q1: What type of motor is compatible with this soft starter?
A: Three-phase squirrel cage induction motors.
Q2: Does it provide speed regulation?
A: No, it only controls motor starting and stopping.
Q3: Can it be used with pump systems?
A: Yes, it is suitable for pump applications to reduce startup shock.
Q4: Is any programming required?
A: No programming is required for basic operation.
Q5: Does it include motor protection?
A: Yes, it provides integrated electronic protection functions.
Q6: Can it operate independently?
A: Yes, it can operate without external controllers.
Q7: Does it support communication networks?
A: No, it does not include communication interfaces.
Q8: Is it suitable for frequent starting cycles?
A: It is intended for standard industrial duty cycles.
Q9: Does it reduce mechanical stress?
A: Yes, it reduces torque spikes during motor startup.
Q10: Is it suitable for replacement projects?
A: Yes, it is commonly used in retrofit and upgrade applications.
