The Schneider Electric ATV950U75N4E is a 7.5 kW class variable speed drive from the Altivar Process 950 series, designed for industrial process environments that demand high efficiency, robust torque control, and advanced digital connectivity.
It is commonly applied in mining equipment, conveyors, crushers, pumps, mixers, HVAC systems, and wastewater treatment plants, where continuous-duty performance and stable motor behavior are essential for operational reliability.
As part of Schneider Electric’s process automation ecosystem, the drive integrates embedded intelligence for energy monitoring, asset diagnostics, and real-time process control, enabling seamless integration with SCADA, PLC, and IIoT platforms. Its IP55-rated wall-mounted design supports decentralized installation close to machinery, reducing cabinet space requirements and simplifying system architecture.
Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ATV950U75N4E |
| Series | Altivar Process ATV950 |
| Device Type | Variable Speed Drive (VFD) |
| Rated Power | 7.5 kW (normal duty) / 5.5 kW heavy duty |
| Supply Voltage | 380–480 V, 3-phase |
| Output Current | 16.5 A nominal |
| Output Frequency | 0.1 – 500 Hz |
| Motor Compatibility | Asynchronous & synchronous motors |
| Control Modes | V/F control, sensorless vector control |
| Overload Capacity | 120% (60 s), higher in derated operation |
| Protection Class | IP55 |
| Communication | Modbus TCP, Ethernet/IP, Modbus RTU, expandable fieldbus options |
| Installation | Wall-mounted decentralized industrial enclosure |
Physical Dimensions & Weight
| Attribute | Value |
|---|---|
| Height | 678 mm |
| Width | 264 mm |
| Depth | 330 mm |
| Weight | approx. 13.7 kg |
The enclosure is designed for industrial durability, thermal stability, and easy field installation, making it suitable for harsh operating environments and decentralized automation layouts.
Recommended Related Models
- Schneider ATV950U55N4E – 5.5 kW enhanced connectivity variant
- Schneider ATV950U90N4 – higher power industrial process applications
- Schneider ATV950D11N4 / D15N4 series – heavy-duty decentralized drives
- Schneider ATV950U75N4 (standard version) – same power class without extended options
- Schneider ATV930U75N4 – cabinet-mounted alternative platform
