The Bently Nevada 330709-000-070-10-02-00 is a 3300 XL 11 mm proximity probe designed for high-accuracy, non-contact measurement of shaft vibration and displacement in rotating machinery.
It is part of the Bently Nevada 3300 XL proximity transducer system, using eddy current sensing technology for reliable condition monitoring and machinery protection. This model features an M16 × 1.5 thread, 70 mm overall case length, 1.0 m cable length, and a miniature coaxial ClickLoc connector with standard cable.
Technical Specifications
| Item | Specification |
|---|
| Brand | Bently Nevada |
| Series | 3300 XL |
| Model | 330709-000-070-10-02-00 |
| Product Type | 11 mm Proximity Probe |
| Measurement Principle | Eddy Current |
| Measurement Function | Shaft vibration & displacement |
| Probe Diameter | 11 mm |
| Thread Type | M16 × 1.5 |
| Unthreaded Length | 0 mm |
| Overall Case Length | 70 mm |
| Total Cable Length | 1.0 m |
| Connector Type | Miniature coaxial ClickLoc connector |
| Cable Type | Standard cable |
| Armor | Without armor |
| Approval Option | No agency approval required |
| Application | Rotating machinery condition monitoring |
Dimensions & Weight
| Item | Specification |
|---|
| Dimensions (L × W × H) | 100 × 100 × 30 mm |
| Weight | 2.00 kg |
Recommended Related Models
| Model | Description |
|---|
| 330709-000-050-10-02-00 | 50 mm case length version |
| 330709-000-060-10-02-00 | 60 mm case length version |
| 330709-000-080-10-02-00 | 80 mm case length version |
| 330704 Series | 11 mm standard proximity probe |
| 330705 Series | 11 mm reverse mount probe |
| 330780 Series | Proximitor sensor |
