The Bently Nevada 330709-000-130-10-02-00 is a 3300 XL 11 mm proximity probe designed for non-contact measurement of shaft vibration, displacement, and position in rotating machinery.
It is part of the Bently Nevada 3300 XL 11 mm Proximity Transducer System, which uses eddy current technology for accurate and reliable monitoring of critical rotating equipment. The 11 mm probe tip provides a longer linear measurement range than standard 8 mm systems and is commonly used for axial position, vibration, and thrust monitoring applications.
Technical Specifications
| Item | Specification |
|---|---|
| Brand | Bently Nevada |
| Series | 3300 XL |
| Model | 330709-000-130-10-02-00 |
| Product Type | 11 mm Proximity Probe |
| Measurement Principle | Eddy Current |
| Measurement Function | Shaft vibration / displacement / position |
| Probe Diameter | 11 mm |
| Thread Type | M16 × 1.5 |
| Unthreaded Length | 0 mm |
| Overall Case Length | 130 mm |
| Total Cable Length | 1.0 m |
| Connector Type | Miniature coaxial ClickLoc connector with connector protector |
| Cable Type | Standard cable |
| Armor | Without armor |
| Agency Approval | Not required |
| Application | Rotating machinery condition monitoring |
Dimensions & Weight
| Item | Specification |
|---|---|
| Dimensions (L × W × H) | Approx. 130 × 11 × 11 mm (probe body) |
| Package Dimensions | Approx. 28 × 23 × 124 mm (supplier listed) |
| Weight | Approx. 0.20 kg |
Model Code Breakdown
330709 - 000 - 130 - 10 - 02 - 00
| Code | Meaning |
|---|---|
| 330709 | 3300 XL 11 mm probe, M16 × 1.5 thread, without armor |
| 000 | 0 mm unthreaded length |
| 130 | 130 mm overall case length |
| 10 | 1.0 m total cable length |
| 02 | Miniature coaxial ClickLoc connector, standard cable |
| 00 | No agency approval required |
Recommended Related Models
| Model | Description |
|---|---|
| 330709-000-060-10-02-00 | 60 mm case length version |
| 330709-000-070-10-02-00 | 70 mm case length version |
| 330709-000-080-10-02-00 | 80 mm case length version |
| 330709-000-090-10-02-00 | 90 mm case length version |
| 330709-000-130-10-02-05 | Same length with approval option |
| 330780 Series | Proximitor sensor |
