The Bently Nevada 330709-050-120-10-02-00 Proximity Probe is a high-performance 3300 XL 11 mm sensing solution designed for accurate shaft vibration and displacement measurement in critical rotating machinery applications. Developed for continuous condition monitoring, this proximity probe delivers stable, repeatable performance for equipment where operational reliability and predictive maintenance are essential.
Featuring an M16 x 1.5 threaded configuration, 120 mm overall case length, 50 mm unthreaded length option, and a 1.0 meter standard cable, this model provides a flexible installation solution for various industrial machinery designs. The miniature coaxial ClickLoc connector ensures convenient integration with compatible monitoring systems while maintaining dependable signal transmission.
With proven eddy current sensing technology, the 330709-050-120-10-02-00 helps maintenance teams monitor machine health, identify abnormal operating conditions, and improve asset availability in demanding industrial environments.
Technical Specifications and Engineering Details
The 330709-050-120-10-02-00 combines accurate sensing capability with a durable mechanical design, making it suitable for long-term operation in industrial monitoring systems.
| Specification | Details |
|---|---|
| Manufacturer | Bently Nevada |
| Model Number | 330709-050-120-10-02-00 |
| Product Type | 3300 XL 11 mm Proximity Probe |
| Sensor Technology | Eddy Current Non-Contact Measurement |
| Probe Diameter | 11 mm |
| Thread Type | M16 x 1.5 |
| Unthreaded Length | 50 mm |
| Overall Case Length | 120 mm |
| Cable Length | 1.0 meter (3.3 ft) |
| Cable Type | Standard Cable |
| Connector Type | Miniature Coaxial ClickLoc Connector |
| Armor Option | Without Armor |
| Measurement Function | Shaft Vibration and Position Monitoring |
| Mounting Method | Threaded Installation |
| Housing Material | Stainless Steel |
| Operating Application | Rotating Machinery Condition Monitoring |
| Product Dimensions | Approx. 120 mm × 11 mm probe body size |
| Product Weight | Approx. 0.20 kg |
The 120 mm case length configuration provides additional mounting flexibility compared with standard compact models, making it suitable for machinery requiring increased installation depth while maintaining accurate measurement performance.
Recommended Related Models for Monitoring System Configuration
Selecting the correct probe configuration helps ensure compatibility, measurement accuracy, and efficient maintenance planning. The following models are commonly considered for similar applications:
| Model | Description |
|---|---|
| Bently Nevada 330709-000-050-10-02-00 | 3300 XL 11 mm Proximity Probe, 50 mm Case Length |
| Bently Nevada 330709-050-150-10-02-00 | 3300 XL 11 mm Proximity Probe, Extended Length Configuration |
| Bently Nevada 330709-016-120-10-02-00 | 3300 XL 11 mm Proximity Probe Variant |
| Bently Nevada 330730 | Extension Cable |
| Bently Nevada 330180 | Proximity Transducer System |
These related products provide additional options for different machine layouts, installation requirements, and monitoring system designs.
Popular Bently Nevada Machinery Monitoring Models
Bently Nevada offers a wide range of industrial monitoring products designed to support equipment reliability, vibration analysis, and asset protection programs.
| Model | Product Category |
|---|---|
| Bently Nevada 3300 XL Series | Proximity Measurement System |
| Bently Nevada 3500/42M | Proximity Monitoring Module |
| Bently Nevada 3500/22M | Data Interface Module |
| Bently Nevada 3500/25 | Keyphasor Module |
| Bently Nevada 3500/15 | Power Supply Module |
These products are widely used in industrial facilities where continuous monitoring and early fault detection are important for maintaining production efficiency.
