Product Introduction and Engineering Overview

The Bently Nevada 3500/25-01-00 Enhanced Bond Phase Module is a precision interface component designed to provide reliable phase reference processing within advanced machinery protection systems. By delivering accurate Keyphasor® signal management, it enables detailed analysis of rotating equipment performance.

This module plays an important role in applications where accurate timing information is required for vibration analysis, shaft position monitoring, and machine balancing. Its integration into the 3500 platform allows engineers to combine phase reference information with other monitoring parameters for comprehensive equipment assessment.

Designed for industrial reliability, the 3500/25-01-00 helps improve machinery diagnostics, increase monitoring accuracy, and support proactive maintenance strategies for critical rotating assets.

Technical Specifications

Specification	Details
Product Brand	Bently Nevada
Model Number	3500/25-01-00
Product Series	3500 Machinery Protection System
Module Type	Enhanced Bond Phase Module
Function	Phase Reference and Keyphasor® Signal Processing
Input Type	Rotational Phase Reference Signals
Application	Rotating Machinery Monitoring and Diagnostics
System Compatibility	Bently Nevada 3500 Monitoring Platform
Installation Type	Rack Mount Module
Dimensions	119.9 × 24.4 × 256.5 mm
Weight	0.34 kg (0.75 lb)

Recommended Related Models

Model	Description
Bently Nevada 3500/25-01-01	Enhanced Keyphasor Module for phase reference applications
Bently Nevada 3500/05	3500 System Rack for module installation
Bently Nevada 3500/15	3500 Power Supply Module for rack power management
Bently Nevada 3500/42M	Proximity Monitor Module for vibration and position monitoring

Popular Related Models

Model	Description
Bently Nevada 3500/22	Transient Data Interface Module for machinery event recording
Bently Nevada 3500/32	4-Channel Relay Module for alarm and protection control
Bently Nevada 3500/40M	Four-Channel Proximity Monitor Module
Bently Nevada 3500/53	Overspeed Detection Module for critical machinery protection

Applications in Phase Reference and Machinery Synchronization Monitoring

The Bently Nevada 3500/25-01-00 Enhanced Bond Phase Module is designed to provide accurate phase reference signal processing and Keyphasor® functionality within the 3500 Machinery Protection System. This module supports precise rotational speed and phase measurement, enabling advanced analysis of shaft position, vibration behavior, and machine operating conditions.

Ideal for critical rotating equipment such as turbines, compressors, generators, and large industrial machinery, the 3500/25-01-00 provides reliable phase data required for vibration analysis, balancing operations, and advanced machinery diagnostics. Its enhanced design improves signal processing capability while maintaining compatibility with the Bently Nevada 3500 platform.

With dependable performance and efficient system integration, this module helps engineers achieve more accurate machinery assessments, improve fault identification, and enhance the overall effectiveness of predictive maintenance programs.

Core Functions and Technical Advantages

Feature	Description
Enhanced Phase Processing	Provides accurate rotational phase and speed measurement
Keyphasor® Signal Support	Enables shaft reference timing for vibration analysis
3500 System Integration	Designed for use within Bently Nevada 3500 monitoring racks
Multi-Channel Capability	Supports multiple phase reference inputs
High Signal Accuracy	Improves machine diagnostic and balancing applications
Compact Rack Design	Allows efficient installation in protection system configurations

Technical FAQs

1. What is the main function of the Bently Nevada 3500/25-01-00?
It processes phase reference signals and provides Keyphasor® input functionality for the 3500 monitoring system.

2. Why is phase reference data important in machinery monitoring?
Phase reference information helps analyze shaft position, vibration behavior, and machine operating characteristics.

3. What type of equipment uses this module?
It is commonly used with turbines, compressors, generators, and other critical rotating machinery.

4. How does the module support vibration analysis?
It provides timing reference signals that allow accurate interpretation of vibration measurements.

5. What is the purpose of Keyphasor® signals?
Keyphasor® signals provide a once-per-revolution reference point for shaft position and phase measurements.

6. Can the module be integrated into an existing 3500 rack?
Yes. It is designed specifically for installation within the Bently Nevada 3500 Machinery Protection System.

7. How does this module improve machinery diagnostics?
It provides accurate phase information that helps engineers analyze vibration patterns and equipment behavior.

8. Is the module used for continuous monitoring applications?
Yes. It supports permanent machinery protection and condition monitoring installations.

9. What affects phase measurement accuracy?
Signal quality, sensor installation, shaft reference setup, and system configuration influence measurement accuracy.

10. What maintenance benefits does this module provide?
It improves diagnostic capability, supports balancing procedures, and helps identify abnormal machinery conditions.
