Bently Nevada 3500/25-01-01-00 Enhanced Bond Phase Module
Bently Nevada 3500/25-01-01-00 Enhanced Bond Phase Module
0.0
Points
Brand:Bently Nevada PLC Item No.:3500/25-01-01-00 Product Origin:USA Product Dimensions:119.9 x 24.4 x 256.5 mm Product Weight:0.34 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Bently Nevada 3500/25-01-01-00 Enhanced Bond Phase Module is a precision monitoring interface designed for reliable phase reference signal processing in industrial machinery protection applications. It provides essential rotational timing information that supports accurate analysis of vibration, shaft position, and machine performance.
As part of the Bently Nevada 3500 platform, this module integrates seamlessly with other monitoring components to deliver comprehensive equipment condition information. Its enhanced design supports applications where accurate phase measurement and dependable signal processing are critical.
Built for demanding industrial environments, the 3500/25-01-01-00 helps improve machine diagnostics, optimize maintenance planning, and enhance the reliability of rotating equipment protection systems.
Technical Specifications
Specification
Details
Product Brand
Bently Nevada
Model Number
3500/25-01-01-00
Product Series
3500 Machinery Protection System
Module Type
Enhanced Bond Phase Module
Function
Phase Reference and Keyphasor® Signal Processing
Input Type
Rotational Phase Reference Signals
Application
Rotating Machinery Monitoring and Diagnostics
System Compatibility
Bently Nevada 3500 Monitoring Platform
Installation Type
Rack Mount Module
Dimensions
119.9 × 24.4 × 256.5 mm
Weight
0.34 kg (0.75 lb)
Recommended Related Models
Model
Description
Bently Nevada 3500/25-01-00
Enhanced Bond Phase Module for phase reference applications
Bently Nevada 3500/05
3500 System Rack for module installation
Bently Nevada 3500/15
3500 Power Supply Module for rack power management
Bently Nevada 3500/22
Transient Data Interface Module for machinery event recording
Popular Related Models
Model
Description
Bently Nevada 3500/32
4-Channel Relay Module for alarm and protection control
Bently Nevada 3500/40M
Four-Channel Proximity Monitor Module
Bently Nevada 3500/42M
Proximity Monitor Module for vibration and position monitoring
Bently Nevada 3500/53
Overspeed Detection Module for critical machinery protection
Applications in Advanced Machinery Phase Reference Monitoring
The Bently Nevada 3500/25-01-01-00 Enhanced Bond Phase Module is designed to provide accurate phase reference processing and Keyphasor® signal management within the Bently Nevada 3500 Machinery Protection System. This module plays an important role in capturing rotational timing information, supporting precise vibration analysis, shaft position monitoring, and advanced machinery diagnostics.
Designed for critical rotating equipment such as turbines, compressors, generators, and large industrial machinery, the 3500/25-01-01-00 provides reliable phase data required for balancing, operational analysis, and machine condition evaluation. Its enhanced processing capability allows maintenance teams to obtain clearer insights into equipment behavior during normal and changing operating conditions.
With dependable integration into the 3500 platform, this module helps improve diagnostic accuracy, strengthen machinery protection strategies, and support efficient predictive maintenance programs for high-value industrial assets.
Technical Capabilities and Product Advantages
Feature
Description
Enhanced Phase Processing
Provides accurate rotational phase reference signal handling
Keyphasor® Interface Function
Supports shaft timing and phase measurement applications
3500 System Compatibility
Designed for integration with Bently Nevada 3500 monitoring racks
High-Precision Signal Processing
Improves vibration analysis and machine diagnostics
Industrial Reliability Design
Supports continuous operation in demanding environments
Compact Rack Installation
Enables efficient integration into protection system configurations
Technical FAQs
1. What is the main function of the Bently Nevada 3500/25-01-01-00?
It processes phase reference signals and provides Keyphasor® functionality for the Bently Nevada 3500 monitoring system.
2. Why is phase reference information important in machinery monitoring?
Phase reference data helps engineers analyze shaft position, vibration characteristics, and rotating equipment behavior.
3. What equipment commonly uses this module?
It is commonly used with turbines, compressors, generators, and other critical rotating machinery.
4. How does the module support vibration diagnostics?
It provides timing reference information that improves the accuracy of vibration analysis.
5. What is the purpose of Keyphasor® signals?
Keyphasor® signals provide a precise shaft rotation reference used for phase and speed measurements.
6. Can this module be installed in an existing 3500 system?
Yes. It is designed specifically for use with Bently Nevada 3500 monitoring system racks.
7. How does accurate phase measurement benefit machinery analysis?
It allows engineers to better understand vibration sources, shaft movement, and machine operating conditions.
8. What factors influence phase signal accuracy?
Sensor installation quality, signal condition, shaft reference setup, and system configuration affect performance.
9. Is this module suitable for continuous machinery protection applications?
Yes. It is designed for permanent installation in industrial monitoring systems.
10. What maintenance advantages does this module provide?
It improves diagnostic information availability and supports proactive maintenance decisions.
