The Yokogawa ADV142-P13 Analog Input Module is a high-precision, versatile solution for industrial automation systems that require accurate and reliable analog signal processing. Whether used in power generation, oil & gas, chemical processing, or manufacturing applications, the ADV142-P13 ensures precise measurement and monitoring of critical process variables such as temperature, pressure, flow, and level. This module integrates seamlessly with Yokogawa's Distributed Control Systems (DCS), Programmable Logic Controllers (PLCs), and SCADA systems, providing real-time data acquisition and control for enhanced process efficiency and safety.

With support for multiple input types—including voltage, current, RTD, and thermocouple—the ADV142-P13 offers exceptional flexibility. This allows for the integration of diverse measurement requirements, making it a vital component for a wide range of industrial processes. Whether you're optimizing process control in a large-scale plant or managing complex automation tasks, the ADV142-P13 provides the accuracy and reliability needed for the most demanding applications.

Technical Specifications

Model: ADV142-P13
Type: Analog Input Module
Input Types:
- Voltage (0-10V, 1-5V, etc.)
- Current (4-20mA)
- RTD (Resistance Temperature Detector)
- Thermocouple (Types J, K, T, R, S, N, B, E)
Number of Channels: 8 or 16 channels (configurable based on model variant)
Accuracy:
- Analog Inputs: ±0.1% of full scale
- RTD Inputs: ±0.2% of full scale
- Thermocouple Inputs: ±0.5% of full scale
Signal Conversion Speed: 200 ms per channel
Power Supply: 24 VDC
Mounting Type: DIN rail or panel mount
Operating Temperature Range: -20°C to 60°C (-4°F to 140°F)
Dimensions (L x W x H): 6.7 x 4.1 x 2.6 inches (170 x 105 x 66 mm)
Weight: 1.4 lbs (635 g)
Communication Protocols: Yokogawa proprietary protocol, Modbus RTU, OPC
LED Indicators: Power, I/O status, Communication status

Recommended Related Models

Yokogawa FA-M3 PLC: A modular, high-performance PLC system that integrates with the ADV142-P13 to handle complex automation processes across various industries.
Yokogawa YS1700: A precision transmitter ideal for measuring critical process variables such as temperature, pressure, and flow, complementing the ADV142-P13 for efficient control and monitoring.
Yokogawa ADMAG AXF: Magnetic flowmeters for accurate flow measurements, working seamlessly with the ADV142-P13 for reliable and consistent flow control.
Yokogawa DPharp EJA: High-accuracy pressure transmitters that pair with the ADV142-P13 for precise pressure monitoring in industrial applications.

Popular Yokogawa Models

Yokogawa CENTUM VP: A leading Distributed Control System (DCS) that integrates perfectly with the ADV142-P13, providing real-time monitoring and advanced process control.
Yokogawa RX3i PLC: A flexible and scalable PLC system designed to integrate with the ADV142-P13 for reliable, high-performance process control.
Yokogawa YS1000: A smart transmitter used for highly accurate measurement of temperature, pressure, and flow, working in conjunction with the ADV142-P13 for precise process control.
Yokogawa EJX Series: High-performance transmitters that seamlessly integrate with the ADV142-P13, offering accurate and consistent measurement of process variables.

Applications

The Yokogawa ADV142-P13 Analog Input Module is ideal for use in industries where accurate, real-time monitoring and control of critical process variables are essential. Some of the key applications include:

Power Generation: The ADV142-P13 is used to monitor key parameters such as turbine temperature, pressure, and flow, ensuring the safe and efficient operation of power plants.
Oil & Gas: The module is essential in monitoring wellhead pressure, temperature, and flow rates in both upstream and downstream oil and gas operations, helping to improve safety and operational performance.
Chemical Processing: In chemical plants, the ADV142-P13 ensures accurate monitoring of temperature, pressure, and flow in reactors and production systems, ensuring product quality and process stability.
Manufacturing Automation: The ADV142-P13 helps monitor production processes by providing real-time data on key parameters, reducing downtime, and improving product consistency in manufacturing environments.
Water and Wastewater Treatment: The module is used in water treatment plants to monitor and control pumps, valves, and chemical dosing systems, ensuring regulatory compliance and efficient operations.
HVAC and Building Automation: The ADV142-P13 is used to monitor environmental conditions such as temperature and humidity in large buildings, improving energy efficiency and occupant comfort.

Advantages

High-Precision Measurements: With ±0.1% accuracy for analog inputs, ±0.2% for RTD inputs, and ±0.5% for thermocouple inputs, the ADV142-P13 ensures precise and reliable signal acquisition.
Versatile Input Types: The ADV142-P13 supports a broad range of input signals, including voltage, current, RTD, and thermocouple, providing exceptional flexibility for diverse applications.
Seamless Integration: Fully compatible with Yokogawa’s DCS, PLC, and SCADA systems, the ADV142-P13 integrates effortlessly into existing automation infrastructure.
Fast Signal Conversion: The ADV142-P13 features a conversion speed of 200 ms per channel, providing real-time data acquisition for quick decision-making.
Durable and Reliable: Designed to withstand industrial environments, the ADV142-P13 operates within a temperature range of -20°C to 60°C, ensuring reliable performance in tough conditions.
Compact Design: Despite its powerful capabilities, the ADV142-P13 has a compact design, allowing for easy integration into space-constrained control panels and automation systems.

Technical FAQs

What types of input signals can the ADV142-P13 process?
- The ADV142-P13 can process voltage (0-10V, 1-5V), current (4-20mA), RTD, and thermocouple inputs (Types J, K, T, R, S, N, B, E).
What is the accuracy of the ADV142-P13 for temperature measurements?
- The module provides ±0.2% accuracy for RTD inputs and ±0.5% for thermocouple inputs.
How many channels does the ADV142-P13 support?
- The ADV142-P13 is available with either 8 or 16 configurable channels.
What is the signal conversion speed of the ADV142-P13?
- The ADV142-P13 has a signal conversion speed of 200 ms per channel, ensuring rapid data acquisition.
What power supply does the ADV142-P13 require?
- The ADV142-P13 operates with a 24 VDC power supply.
Can the ADV142-P13 be integrated with other Yokogawa products?
- Yes, the ADV142-P13 is fully compatible with Yokogawa’s DCS, PLCs, and SCADA systems, offering seamless integration into existing automation systems.
What is the operating temperature range for the ADV142-P13?
- The ADV142-P13 operates in a temperature range of -20°C to 60°C (-4°F to 140°F).
What are the dimensions of the ADV142-P13 module?
- The ADV142-P13 measures 6.7 x 4.1 x 2.6 inches (170 x 105 x 66 mm).
How is the ADV142-P13 mounted?
- The module can be mounted on a DIN rail or directly onto a panel for flexible installation.
Is the ADV142-P13 suitable for hazardous environments?
