Brand:GE Fanuc PLC Item No.:IC200MDL241B Product Origin:USA Product Dimensions:109 × 64 × 58 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200MDL241B Discrete Input Module is a dependable 240 VAC digital input solution designed for GE VersaMax automation platforms. It provides 16 discrete input channels for collecting ON/OFF signals from industrial field devices and transferring them into PLC control logic.
Built for industrial reliability, the module combines compact installation, optical isolation, and individual channel diagnostics to support efficient machine control and system maintenance. Its flexible two-group input structure makes it suitable for a wide range of factory automation and process control applications.
The IC200MDL241B is widely used in modernization projects where existing VersaMax installations require dependable replacement hardware while maintaining the original control architecture.
Technical Specifications
Specification
Description
Manufacturer
GE Fanuc / Emerson
Model
IC200MDL241B
Product Type
Discrete Input Module
Product Family
VersaMax I/O System
Input Type
240 VAC Positive Logic Input
Number of Inputs
16 Points
Input Groups
2 Groups of 8 Inputs
Input Voltage Range
0 to 264 VAC
Nominal Input Voltage
240 VAC
Input Frequency
47 to 63 Hz
ON State Voltage
155 to 264 VAC
OFF State Voltage
0 to 40 VAC
ON State Current
7 mA Minimum
Input Impedance
38.5 kΩ Typical at 60 Hz
Isolation
Optical Isolation
Isolation Rating
1500 VAC for 1 minute
Response Time
1 Cycle ON / 2 Cycles OFF
Indicators
16 Input LEDs + OK LED
Backplane Current Consumption
110 mA Maximum at 5 VDC
External Power Supply
Not Required
Mounting Type
VersaMax Carrier / DIN Rail Installation
Dimensions
Approximately 110 × 66.8 × 50 mm
Weight
Approximately 0.28 kg
Recommended Companion Models
Model
Product Name
IC200MDL240
VersaMax 120 VAC 16-Point Discrete Input Module
IC200MDL650
VersaMax 24 VDC 16-Point Discrete Input Module
IC200PWR101
VersaMax Power Supply Module
IC200CPU001
VersaMax CPU Module
Frequently Selected Alternatives
Model
Product Name
IC693MDL645F
Series 90-30 24 VDC 16-Point Input Module
IC693MDL634
Series 90-30 24 VDC 8-Point Input Module
IC693MDL640
Series 90-30 24 VDC 16-Point Input Module
IC200MDL240
VersaMax 120 VAC 16-Point Input Module
Where It Excels in Industrial Use
AC signal monitoring in GE VersaMax PLC automation systems
Factory automation and production line control
Machine status feedback and equipment diagnostics
Industrial switch and sensor signal acquisition
Motor starter and contactor monitoring applications
Process automation systems requiring 240 VAC digital inputs
Packaging, assembly, and material handling equipment
Legacy GE Fanuc automation system maintenance
Distributed I/O applications using VersaMax platforms
Industrial control cabinets requiring compact AC input expansion
Key Strengths at a Glance
16-point 240 VAC discrete input capability
Two groups of eight input channels for flexible field wiring
Positive logic and sourcing-type input operation
Optical isolation between field inputs and PLC logic
Individual LED indicators for each input channel
No external field power supply required
Compact VersaMax I/O module design
Fast input response for industrial control applications
Reliable operation in demanding automation environments
Suitable for system upgrades and replacement projects
Technical FAQs
1. What is the main function of the GE IC200MDL241B?
The IC200MDL241B is a VersaMax discrete input module designed to receive 240 VAC ON/OFF signals from field devices and provide digital input data to the PLC control system.
2. How many input channels does the IC200MDL241B provide?
The module provides 16 discrete input points arranged in two groups of eight channels.
3. What type of input signals can be connected?
It accepts 240 VAC discrete signals from devices such as switches, sensors, relay contacts, and other industrial field equipment.
4. Does the module require an external power supply?
No. The module receives operating power from the VersaMax backplane and does not require a separate external module power source.
5. What isolation protection does the module provide?
The module provides optical isolation between user inputs, logic circuits, and frame ground, supporting 250 VAC continuous isolation and 1500 VAC isolation for one minute.
6. How are input states displayed?
Each input channel has an individual LED indicator showing the ON/OFF status of the corresponding field signal.
7. What PLC platform is compatible with this module?
The IC200MDL241B is designed for GE VersaMax I/O and control systems.
8. What is the typical input voltage range?
The module accepts 0 to 264 VAC input signals with 240 VAC as the nominal operating voltage.
9. How does the module improve troubleshooting efficiency?
Channel-level LED diagnostics allow technicians to quickly identify active inputs and simplify field troubleshooting during commissioning and maintenance.
10. What applications commonly use this module?
Typical applications include industrial machinery, production lines, process equipment, and automation systems requiring reliable AC digital input monitoring.
