Brand:Bently Nevada PLC Item No.: IC693MDL753F Product Origin:USA Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC693MDL753F Discrete Output Module is a high-density 12/24 VDC output solution designed for GE Fanuc Series 90-30 PLC automation systems. Featuring 32 positive logic output channels, this module provides efficient control of industrial DC devices while maintaining dependable performance in demanding manufacturing environments.
With four isolated output groups, optical protection, and fast switching capability, the IC693MDL753F offers a flexible and reliable interface between PLC logic and field equipment. It is especially suitable for applications requiring multiple DC loads to be controlled within a compact PLC rack configuration.
Designed for long-term industrial operation, this module remains a practical choice for automation upgrades, maintenance projects, and legacy Series 90-30 system support.
Technical Specifications
Specification
Description
Manufacturer
GE Fanuc / Emerson
Model
IC693MDL753F
Product Type
Discrete Output Module
PLC Platform
Series 90-30
Output Type
12/24 VDC Positive Logic (Sourcing)
Number of Outputs
32 Points
Output Groups
4 Groups × 8 Outputs
Output Voltage Range
10.2 to 28.8 VDC
Nominal Voltage
12/24 VDC
Output Current
0.5 A per Point
Maximum Group Current
4 A per Group
Common Pin Current
3 A Maximum
Isolation
1500 VAC Field Side to Logic Side
Output Voltage Drop
0.3 VDC Maximum
Off-State Leakage Current
0.1 mA Maximum
Response Time
0.5 ms Maximum ON/OFF
Inrush Current
5.4 A for 10 ms
Indicators
Individual Output LEDs
Backplane Current Consumption
260 mA at 5 VDC
Mounting Type
Single PLC I/O Slot
Connection Type
24-Pin Front Connectors
Dimensions
Approx. 140 × 130 × 35 mm
Weight
Approx. 0.26 kg
Recommended Companion Models
Model
Product Name
IC693CPU374
Series 90-30 Ethernet CPU Module
IC693PWR321
Series 90-30 Power Supply Module
IC693MDL645F
24 VDC 16-Point Discrete Input Module
IC693MDL753
12/24 VDC 32-Point Positive Logic Output Module
Frequently Selected Alternatives
Model
Product Name
IC693MDL754
Series 90-30 32-Point Relay Output Module
IC693MDL750
Series 90-30 12/24 VDC Positive Logic Output Module
IC200MDL740
VersaMax 16-Point Relay Output Module
IC200MDL753
VersaMax 32-Point 12/24 VDC Output Module
Where It Excels in Industrial Use
GE Fanuc Series 90-30 PLC automation systems
High-density DC actuator control applications
Solenoid valve and relay control systems
Motor starter and indicator control circuits
Packaging and assembly machinery
Material handling and conveyor automation
Industrial equipment retrofit projects
Factory production line control
Machine sequencing and discrete output management
Distributed control applications requiring reliable 12/24 VDC outputs
Four isolated output groups with eight channels each
Supports sourcing output operation for industrial DC loads
0.5 A output current capacity per point
Fast 0.5 ms maximum response time
Optical isolation improves system protection
Individual LED indicators simplify troubleshooting
Single-slot installation for Series 90-30 PLC systems
Flexible wiring through front-panel connectors
Reliable solution for demanding industrial automation environments
Technical FAQs
1. What is the main function of the GE IC693MDL753F?
The IC693MDL753F is a 12/24 VDC positive logic discrete output module designed to control DC field devices connected to GE Fanuc Series 90-30 PLC systems.
2. How many output channels does the IC693MDL753F provide?
The module provides 32 discrete output points arranged into four independent groups of eight outputs.
3. What type of output logic does this module use?
The IC693MDL753F uses positive logic (sourcing) outputs, meaning it switches the positive side of the DC supply to deliver current to connected loads.
4. What devices can be controlled with this output module?
Typical connected devices include solenoid valves, indicator lamps, relays, contactors, and other 12/24 VDC industrial loads.
5. What is the maximum output current per channel?
Each output point can provide up to 0.5 A of current, with group and common terminal current limitations depending on wiring configuration.
6. Does the module provide electrical isolation?
Yes. The module uses opto-isolation between field-side circuits and PLC logic circuits to improve system protection and reliability.
7. What PLC platform is compatible with the IC693MDL753F?
The module is designed for GE Fanuc Series 90-30 PLC systems and can be installed in compatible I/O slots.
8. How are output states monitored?
Each output channel includes an LED indicator that provides visual confirmation of output activation for easier commissioning and maintenance.
9. What is the response speed of the output module?
The module provides fast switching performance with approximately 0.5 ms maximum ON and OFF response times.
10. Is the IC693MDL753F suitable for replacement applications?
Yes. It is widely used for maintaining existing Series 90-30 PLC installations where reliable DC output control is required.
