GE IC693PWR330H Series 90-30 High Capacity Power Supply Module
GE IC693PWR330H Series 90-30 High Capacity Power Supply Module
0.0
Points
Brand:GE Fanuc PLC Item No.:IC693PWR330H Product Origin:USA Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC693PWR330H Series 90-30 High Capacity Power Supply Module is a robust power management solution designed for GE Fanuc Series 90-30 PLC systems. Developed for applications where standard power supplies may not provide sufficient current capacity, this module delivers enhanced +5 VDC output capability to support larger and more demanding PLC rack configurations.
With support for wide-range AC/DC input operation and multiple output voltage options, the IC693PWR330H provides stable and dependable power distribution for industrial automation systems. Its modular plug-in design simplifies installation while maintaining the reliability expected in continuous production environments.
For engineers maintaining existing Series 90-30 platforms, this high-capacity power supply offers an effective solution for system expansion, replacement, and long-term operational stability.
Technical Specifications
Specification
Description
Manufacturer
GE Fanuc / Emerson
Model
IC693PWR330H
Product Type
High Capacity Power Supply Module
Product Family
Series 90-30
Input Voltage
120/240 VAC or 125 VDC
AC Input Range
85–264 VAC
DC Input Range
100–300 VDC
Total Output Power
30 W Maximum
Main Output
+5 VDC Backplane Supply
+5 VDC Output Capacity
30 W Maximum
Relay Output
+24 VDC, 15 W Maximum
Isolated Output
+24 VDC, 20 W Maximum
Inrush Current
4 A Peak Maximum
Protection
Over-Voltage / Over-Current Protection
Installation Position
Leftmost Baseplate Slot
Communication Interface
RS-485 Compatible Serial Port
Indicators
PWR, OK, System Status LEDs
Battery Support
Lithium Battery Backup Connector
Operating Temperature
0°C to +60°C
Dimensions
Approx. 140 × 130 × 70 mm
Weight
Approx. 0.56 kg
Recommended Companion Models
Model
Product Name
IC693CPU374
Series 90-30 Ethernet CPU Module
IC693CHS391N
Series 90-30 10-Slot CPU Baseplate
IC693CMM311N
Series 90-30 Communications Coprocessor Module
IC693ALG223
Series 90-30 16-Channel Analog Current Input Module
Frequently Selected Alternatives
Model
Product Name
IC693PWR321
Series 90-30 Standard Power Supply Module
IC693PWR322
Series 90-30 Expanded Capacity Power Supply Module
IC693PWR331
Series 90-30 24 VDC High Capacity Power Supply Module
IC695PWR330
PACSystems RX3i High Capacity Power Supply Module
Where It Excels in Industrial Use
GE Fanuc Series 90-30 PLC control systems
Large I/O rack configurations requiring increased 5 VDC capacity
Manufacturing automation control cabinets
Process control systems with multiple I/O modules
Machine builders requiring stable PLC rack power
Industrial retrofit and replacement projects
High-density Series 90-30 installations
Production lines requiring reliable continuous operation
Legacy PLC modernization and maintenance applications
Automation systems operating in demanding industrial environments
Key Strengths at a Glance
High-capacity power supply designed for Series 90-30 PLC platforms
Provides up to 30 W total output power
Delivers full 30 W capacity through the +5 VDC supply rail
Supports wide-range AC and DC input operation
Includes +24 VDC relay power output
Provides isolated +24 VDC output for compatible modules
Integrated over-voltage and over-current protection
Installs directly in the leftmost Series 90-30 rack slot
Supports larger PLC configurations with higher current demand
Proven reliability for long-life industrial automation systems
Technical FAQs
1. What is the primary function of the GE IC693PWR330H?
The IC693PWR330H is a high-capacity power supply module designed to provide operating power for GE Fanuc Series 90-30 PLC racks. It supplies backplane power and additional 24 VDC outputs for compatible modules and field devices.
2. Where is the IC693PWR330H installed in a Series 90-30 rack?
The module is installed in the leftmost slot of the Series 90-30 baseplate, where it provides power to all modules connected through the backplane.
3. What input voltage range does this power supply support?
The IC693PWR330H supports a wide input range of approximately 85–264 VAC or 100–300 VDC, allowing flexible installation in different industrial power environments.
4. What output voltages are provided?
The module provides:
+5 VDC backplane power
+24 VDC relay output power
Isolated +24 VDC output for supported modules and external applications
5. What is the maximum output capacity?
The IC693PWR330H provides a total output capacity of 30 watts, with the ability to allocate the full capacity to the +5 VDC output when required by high-current Series 90-30 configurations.
6. Does the module include protection functions?
Yes. The power supply incorporates protection features including over-voltage and over-current protection to improve PLC system reliability.
7. Can the isolated 24 VDC output power external devices?
Yes. The isolated 24 VDC output can be used internally by compatible modules and may also provide power for certain 24 VDC input modules.
8. Is the IC693PWR330H compatible with Series 90-30 CPUs and I/O modules?
Yes. It is designed specifically for GE Fanuc Series 90-30 PLC racks and supports the power requirements of compatible CPU, communication, and I/O modules.
9. Does this module contain a PLC processor or communication function?
No. The IC693PWR330H is strictly a power supply module and does not execute control logic or provide communication processing.
10. Why is the IC693PWR330H still used in industrial systems?
Its high-capacity output capability and compatibility with established Series 90-30 installations make it a practical replacement choice for maintaining mature automation systems.
