GE IC693CHS391K Series 90-30 10-Slot CPU Baseplate
GE IC693CHS391K Series 90-30 10-Slot CPU Baseplate
0.0
Points
Brand:GE Fanuc PLC Item No.:IC693CHS391K Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC693CHS391K Series 90-30 10-Slot CPU Baseplate is a foundational hardware component designed for GE Fanuc Series 90-30 programmable logic controller systems. It provides the mechanical structure and electrical backplane required to connect CPU modules, power supplies, communication modules, and industrial I/O modules within a centralized PLC rack.
Built for demanding automation environments, the IC693CHS391K offers a practical rack solution for applications requiring multiple control modules while maintaining the modular flexibility of the Series 90-30 architecture. Its 10-slot configuration provides sufficient space for complex automation systems while allowing future expansion.
For factories, OEM equipment, and industrial facilities maintaining Series 90-30 installations, this baseplate remains a dependable choice for PLC system upgrades, replacements, and long-term operational support.
Technical Specifications
Specification
Description
Manufacturer
GE Fanuc / Emerson
Model
IC693CHS391K
Product Type
CPU Baseplate
Product Family
Series 90-30
Baseplate Type
Main CPU I/O Base
Number of Slots
10 Slots
CPU Slot
1 Dedicated CPU Slot
Power Supply Slot
1 Dedicated Power Supply Slot
I/O Slots
8 Additional Module Slots
Compatible CPUs
Series 90-30 CPU Modules
Expansion Connector
25-Pin Female Connector
Backplane Voltage
5 VDC
Internal Power Consumption
420 mA @ 5 VDC
Rack Configuration
Main Baseplate
Mounting Orientation
Horizontal / Vertical
Operating Temperature
0°C to +60°C
Dimensions
Approx. 443 × 130 × 142 mm
Weight
Approx. 1.0 kg
Recommended Companion Models
Model
Product Name
IC693PWR330H
Series 90-30 High Capacity Power Supply Module
IC693CPU374
Series 90-30 Ethernet CPU Module
IC693CMM311N
Series 90-30 Communications Coprocessor Module
IC693ALG223C
Series 90-30 Analog Current Input Module
Frequently Selected Alternatives
Model
Product Name
IC693CHS392C
Series 90-30 10-Slot Expansion Baseplate
IC693CHS393
Series 90-30 10-Slot Remote Baseplate
IC693CHS397
Series 90-30 5-Slot CPU Baseplate
IC693CHS398
Series 90-30 5-Slot Expansion Baseplate
Where It Excels in Industrial Use
GE Fanuc Series 90-30 PLC main rack configurations
Medium and large-scale industrial automation systems
Manufacturing production line control cabinets
Process control systems requiring multiple I/O modules
Machine automation platforms with expandable architectures
Legacy Series 90-30 PLC maintenance and replacement projects
Systems requiring CPU, power supply, and I/O module integration
Industrial equipment modernization applications
Distributed control installations using remote or expansion racks
One CPU slot plus multiple I/O expansion positions
Supports Series 90-30 expansion and remote rack architectures
Includes 25-pin expansion connector interface
Compatible with a wide range of Series 90-30 modules
High-capacity backplane design for complex control systems
Supports horizontal and vertical installation orientations
Provides a stable hardware foundation for long-term PLC operation
Technical FAQs
1. What is the primary function of the GE IC693CHS391K?
The IC693CHS391K is a Series 90-30 10-slot CPU baseplate that provides the physical mounting structure, backplane communication, and power distribution connections for CPU, power supply, and I/O modules in a PLC system.
2. How many module slots does the IC693CHS391K provide?
The baseplate provides 10 total slots, including a dedicated CPU position, a power supply position, and additional slots for I/O or option modules.
3. Which PLC platform uses the IC693CHS391K?
The module is designed for the GE Fanuc Series 90-30 PLC family and supports compatible Series 90-30 CPU, communication, and I/O modules.
4. Can the IC693CHS391K be used as an expansion rack?
No. The IC693CHS391K is primarily a CPU/main baseplate. Expansion and remote baseplate functions are provided by related Series 90-30 baseplate models.
5. What type of modules can be installed on this baseplate?
Compatible modules include Series 90-30 CPUs, discrete input/output modules, analog modules, communication modules, and specialty option modules.
6. Does the IC693CHS391K include a power supply?
No. The baseplate provides a dedicated power supply slot, but the actual power supply module must be installed separately.
7. What communication connection is available on this baseplate?
The baseplate includes a 25-pin female connector used for connection to compatible expansion or remote baseplates in multi-rack systems.
8. What is the maximum number of baseplates supported in a Series 90-30 system?
The supported number of baseplates depends on the installed CPU model. Certain Series 90-30 CPUs support multiple expansion or remote baseplates for larger systems.
9. What is the backplane power requirement of the IC693CHS391K?
The baseplate consumes approximately 420 mA at 5 VDC for internal backplane operation.
10. Why is the IC693CHS391K still widely used?
Its compatibility with the established Series 90-30 platform, flexible slot capacity, and reliable rack architecture make it valuable for maintaining existing industrial automation systems.
