Brand:GE Fanuc PLC Item No.: IC200UDR064 Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200UDR064 Micro PLC Module is a compact VersaMax Micro controller designed for industrial automation applications requiring integrated control, input monitoring, and output switching capabilities. It combines PLC processing functions with 64 points of integrated I/O, making it a practical solution for machine builders and automation engineers working on compact control systems.
With 40 DC input channels and 24 relay outputs, the IC200UDR064 supports a wide range of industrial devices including sensors, switches, actuators, and motor control components. Its flexible input configuration and relay-based output design allow easy adaptation to different automation requirements.
Built for reliable operation in industrial environments, this VersaMax Micro PLC offers efficient control performance, simplified installation, and dependable functionality for standalone machines and distributed automation applications.
Technical Specifications
Parameter
Details
Model
IC200UDR064
Product Type
VersaMax Micro PLC Module
Series
GE VersaMax Micro
I/O Capacity
64 Points
Digital Inputs
40 × 24 VDC Inputs
Input Logic
Positive Logic / Negative Logic
Digital Outputs
24 × Relay Outputs
Output Type
Normally Open Form A Relay
Relay Switching Capacity
2 A per Output
High-Speed Counter Support
Up to 4 Type A or equivalent configurations
Power Supply
24 VDC
Operating Voltage Range
19.2 VDC to 30 VDC
Serial Port Output Supply
+5 VDC, up to 100 mA
Isolation Voltage
1500 V RMS field side to logic side
Input Response Time
Configurable 1 ms to 20 ms
High-Speed Counter Response
Approximately 100 μs
Installation Type
Compact Integrated PLC
Dimensions
Approx. 152 × 89 × 76 mm
Weight
Approx. 580 g
Recommended Companion Models
Model
Product Name
IC200CPUE05
VersaMax Micro CPU Controller Module
IC200USB001
VersaMax Micro RS-232 Communication Option Module
IC200USB002
VersaMax Micro RS-485 Communication Option Module
IC200UMB001
VersaMax Micro Memory Pack Module
Where It Excels in Industrial Use
• Designed for GE VersaMax Micro PLC automation systems, the IC200UDR064 provides compact control capability for machine automation, equipment control, and small-scale industrial applications requiring integrated I/O functionality.
• Suitable for manufacturing equipment, packaging systems, material handling machines, and standalone control applications where reliable digital input monitoring and relay output control are required.
• Ideal for space-conscious automation installations that need a complete PLC solution with built-in power supply, input channels, and output switching capability in a compact controller design.
• Commonly applied in industrial systems requiring flexible field device connection, stable control execution, and straightforward maintenance for long-term operation.
Key Strengths at a Glance
• Integrates 40 configurable 24 VDC positive/negative logic inputs and 24 normally open relay outputs, providing a balanced I/O structure for various automation tasks.
• Supports relay switching capability for controlling devices such as motor starters, solenoids, indicators, and other industrial loads.
• Includes high-speed counter functionality, allowing selected input points to support faster signal processing requirements in motion and counting applications.
• Combines PLC processing, I/O control, and 24 VDC power operation in one compact platform, helping reduce installation complexity and system footprint.
Technical FAQs
1. What type of PLC module is the GE IC200UDR064?
The GE IC200UDR064 is a VersaMax Micro 64-point PLC module with integrated DC inputs, relay outputs, and 24 VDC power supply capability.
2. How many input and output points does the IC200UDR064 provide?
The module provides 40 configurable 24 VDC inputs and 24 normally open relay outputs for industrial control applications.
3. What type of input signals does the IC200UDR064 support?
The module supports 24 VDC positive logic and negative logic input configurations for compatibility with various field devices.
4. What types of devices can be connected to the relay outputs?
The relay outputs can control devices such as contactors, motor starters, solenoids, and indicator equipment within supported electrical limits.
5. Does the IC200UDR064 support high-speed counting functions?
Yes, selected input channels can be configured for high-speed counter applications depending on the system configuration.
6. What communication options are available for this PLC module?
The IC200UDR064 includes a serial communication interface and supports optional communication expansion modules for additional connectivity.
7. What power supply does the IC200UDR064 require?
The module operates with a 24 VDC power supply input and supports an operating range of approximately 19.2 VDC to 30 VDC.
8. Can the IC200UDR064 replace other VersaMax Micro PLC models?
Replacement depends on I/O requirements, output type, power configuration, and existing application programming compatibility.
9. What programming environment is used for the IC200UDR064?
The module is programmed using compatible GE PLC programming software designed for VersaMax Micro controller systems.
10. What should be checked before installing an IC200UDR064?
Engineers should verify power requirements, I/O wiring configuration, communication settings, and application compatibility before installation.
