Brand:GE Fanuc PLC Item No.: IC693MDL940J Product Origin:USA Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC693MDL940J Output Module is a relay-based digital output solution designed for GE Series 90-30 PLC automation platforms. It provides 16 normally open relay outputs that allow PLC programs to control a wide range of industrial devices, including actuators, indicators, contactors, and motor control components.
With support for both AC and DC switching applications, the IC693MDL940J offers engineers greater flexibility when designing industrial control systems. Its relay architecture provides electrical separation between the PLC control side and external field equipment, making it suitable for applications requiring dependable switching performance.
Built for long-term operation in industrial environments, the IC693MDL940J combines flexible load compatibility, reliable relay technology, and proven Series 90-30 integration to support efficient automation system maintenance and expansion.
Technical Specifications
Parameter
Details
Model
IC693MDL940J
Product Type
Relay Output Module
Series
GE Series 90-30
Output Type
Normally Open Relay Output
Number of Outputs
16 Points
Output Groups
4 Groups × 4 Outputs
Rated Voltage
24 VDC, 120 VAC, 240 VAC
Operating Voltage Range
5–30 VDC / 5–250 VAC, 50/60 Hz
Maximum Output Current
2 A per Output
Maximum Current per Common
4 A
Minimum Load Current
10 mA
Maximum Inrush Current
5 A
Isolation
1500 VAC Field Side to Logic Side
Output Response Time
15 ms Maximum
Internal Power Consumption
7 mA at 5 VDC bus; 135 mA at 24 VDC relay bus
Compatible Platform
GE Series 90-30 PLC
Installation Type
Baseplate Mounted Module
Dimensions
Approx. 130 × 40 × 125 mm
Weight
Approx. 0.40 kg
Recommended Companion Models
Model
Product Name
IC693PWR321
Series 90-30 Power Supply Module
IC693CPU374
Series 90-30 Ethernet CPU Module
IC693MDL645
Series 90-30 24 VDC Input Module
IC693CHS397
Series 90-30 10-Slot Baseplate
Where It Excels in Industrial Use
• Designed for GE Series 90-30 PLC systems, the IC693MDL940J provides reliable relay-based output control for industrial automation applications requiring flexible AC and DC load switching capability.
• Suitable for machine automation, motor control systems, production equipment, and process applications where PLC-controlled switching of external devices is required.
• Ideal for controlling field devices such as solenoids, contactors, indicators, motor starters, and other industrial loads that require electrically isolated relay outputs.
• Commonly applied in GE Series 90-30 installations where dependable output switching, long service life, and easy maintenance are important for system reliability.
Key Strengths at a Glance
• Provides 16 normally open relay output points arranged in four groups of four outputs, allowing flexible connection of multiple field devices.
• Supports both AC and DC load applications with operating ranges of 5–30 VDC and 5–250 VAC, 50/60 Hz, improving application versatility.
• Delivers up to 2 A maximum load capacity per output channel and 4 A maximum per common group for reliable industrial switching performance.
• Provides electrical isolation between field circuits and PLC logic circuits, helping protect the control system from external electrical disturbances.
Technical FAQs
1. What type of module is the GE IC693MDL940J?
The GE IC693MDL940J is a 16-point relay output module designed for GE Series 90-30 PLC systems.
2. How many output channels does the IC693MDL940J provide?
The module provides 16 normally open relay output points divided into four groups of four outputs each.
3. What types of loads can the IC693MDL940J control?
The module can control devices such as motor starters, solenoid valves, indicators, and other AC or DC industrial loads within the rated switching limits.
4. What voltage ranges are supported by the IC693MDL940J outputs?
The output circuits support 5–30 VDC and 5–250 VAC at 50/60 Hz, depending on the connected field device requirements.
5. What is the maximum current capacity of each output point?
Each relay output supports up to 2 A maximum pilot duty current, with a maximum of 4 A per common terminal group.
6. Does the IC693MDL940J provide output isolation?
Yes, the module provides isolation between field-side circuits and PLC logic circuits to improve system protection and reliability.
7. Does the IC693MDL940J require external power for field loads?
Yes, users must provide the appropriate AC or DC power source for connected field devices, while relay operation power is supplied through the PLC backplane.
8. What is the response time of the IC693MDL940J relay outputs?
The typical maximum ON and OFF response time is approximately 15 ms.
9. How is output status monitored on the IC693MDL940J?
The module includes LED indicators that display the ON/OFF status of each output point for easier troubleshooting and maintenance.
10. What should be checked before replacing an IC693MDL940J module?
Engineers should verify Series 90-30 compatibility, output wiring configuration, load voltage requirements, and current ratings before replacement.
