GE IC693ALG392B Analog Current/Voltage Output Module
GE IC693ALG392B Analog Current/Voltage Output Module
0.0
Points
Brand:GE Fanuc PLC Item No.:IC693ALG392B Product Origin:USA Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC693ALG392B Analog Current/Voltage Output Module is a versatile industrial control component designed for GE Series 90-30 PLC platforms. With eight configurable analog output channels, it enables precise regulation of field equipment through standard voltage and current signals.
Supporting multiple output ranges, including 4–20 mA, 0–20 mA, 0–10 VDC, and bipolar voltage signals, the IC693ALG392B provides engineers with a flexible solution for integrating analog control functions into existing automation systems.
Built for dependable industrial operation, this module combines high-resolution signal conversion, flexible configuration options, and reliable GE PLC compatibility, making it suitable for system upgrades, maintenance projects, and long-term automation applications.
Technical Specifications
Parameter
Details
Model
IC693ALG392B
Product Type
Analog Current/Voltage Output Module
Series
GE Series 90-30
Output Channels
8 Single-Ended Channels
Output Type
Analog Voltage / Current
Voltage Output Range
0 to +10 VDC / -10 to +10 VDC
Current Output Range
0 to 20 mA / 4 to 20 mA
Resolution
15-bit to 16-bit
Update Rate
8 ms (All Channels)
Current Resolution
0.5 µA at 4–20 mA
Voltage Resolution
0.3125 mV
External Power Supply
20–30 VDC
Internal Supply
5 VDC Backplane Power
Output Load
5 mA Maximum Voltage Mode
Isolation
Field-to-Logic Isolation
Fault Detection
Open Wire Detection in Current Mode
Calibration
Factory Calibrated
Backplane Current Consumption
Approx. 110 mA at 5 VDC
External Current Consumption
Approx. 315 mA at 24 VDC
Mounting Type
Series 90-30 Rack Mounted
Dimensions
Approx. 130 × 140 × 35 mm
Weight
Approx. 0.40 kg
Recommended Companion Models
Model
Product Name
IC693PWR321W
Series 90-30 AC/DC Power Supply Module
IC693CPU374
Series 90-30 Ethernet CPU Module
IC693ALG223D
Series 90-30 Analog Current Input Module
IC693CHS391L
Series 90-30 10-Slot Baseplate Module
Frequently Selected Alternatives
Model
Product Name
IC693ALG391
Series 90-30 16-Channel Analog Current/Voltage Input Module
IC693ALG391G
Series 90-30 Analog Input Module
IC693ALG442
Series 90-30 Analog Combination Input/Output Module
IC693ALG230
Series 90-30 4-Channel Analog Voltage Input Module
Where It Excels in Industrial Use
• Designed for GE Series 90-30 PLC systems, the IC693ALG392B provides flexible analog output control for industrial applications requiring accurate voltage and current signal generation.
• Suitable for process automation, motion control, energy management, manufacturing equipment, and machine systems where analog devices require precise adjustment signals.
• Ideal for controlling variable frequency drives, proportional valves, actuators, positioners, recorders, and other field devices that accept standard analog voltage or current inputs.
• Commonly applied in legacy GE PLC installations where reliable analog regulation, flexible signal selection, and efficient rack integration are required for continued system performance.
Key Strengths at a Glance
• Provides eight single-ended analog output channels with support for both voltage and current signal modes, allowing one module to handle diverse industrial control requirements.
• Supports configurable output ranges including 0 to +10 VDC, -10 to +10 VDC, 0 to 20 mA, and 4 to 20 mA for broad field device compatibility.
• Delivers high-resolution digital-to-analog conversion with 15-bit to 16-bit performance depending on the selected output range, improving control accuracy in demanding applications.
• Includes channel-level fault reporting and external 24 VDC power support, helping simplify system diagnostics and improve operational reliability.
Technical FAQs
1. What type of module is the GE IC693ALG392B?
The GE IC693ALG392B is an 8-channel analog current/voltage output module designed for GE Series 90-30 PLC systems.
2. How many analog output channels does the IC693ALG392B provide?
The module provides eight single-ended analog output channels for voltage and current control applications.
3. What output signal ranges are supported by the IC693ALG392B?
The module supports 0 to +10 VDC, -10 to +10 VDC, 0 to 20 mA, and 4 to 20 mA output ranges.
4. What types of devices can be controlled by the IC693ALG392B?
The module can control analog devices such as variable frequency drives, control valves, positioners, and industrial regulators.
5. What resolution does the IC693ALG392B provide?
The module provides 15-bit to 16-bit output resolution depending on the selected signal range.
6. Does the IC693ALG392B require an external power supply?
Yes. The module requires an external 20–30 VDC supply connected through the terminal block for analog output operation.
7. What is the update rate of the IC693ALG392B?
The module updates all eight output channels approximately every 8 milliseconds.
8. Does the IC693ALG392B support open-wire detection?
Yes. When operating in current output mode, the module can report open-wire faults for individual channels.
9. What PLC platforms are compatible with the IC693ALG392B?
The module is designed for GE Series 90-30 PLC systems and can also be integrated into compatible PACSystems RX3i configurations.
10. What should be checked before replacing an IC693ALG392B?
Engineers should verify PLC compatibility, output signal configuration, external power wiring, field device requirements, and software configuration before replacement.
