Brand:GE Fanuc PLC Item No.: IC200MDD840F Product Origin:USA Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The GE IC200MDD840F Discrete Mixed I/O Module is a versatile VersaMax automation component designed to combine digital input monitoring and relay output control within a single compact module. It provides 20 channels of 24 VDC positive logic input and 12 relay output channels, helping reduce hardware requirements while maintaining flexible industrial connectivity.
Built for distributed control environments, the IC200MDD840F allows PLC systems to collect field device signals and control external equipment through reliable relay switching. This integrated design makes it suitable for applications where efficient cabinet utilization and simplified I/O management are important.
With dependable VersaMax compatibility, flexible field integration, and proven relay output performance, the IC200MDD840F is a practical choice for automation expansion, replacement projects, and long-term industrial operation.
Technical Specifications
Parameter
Details
Model
IC200MDD840F
Product Type
Discrete Mixed I/O Module
Series
GE VersaMax
Input Type
24 VDC Positive Logic Input
Number of Inputs
20 Points
Input Configuration
2 Groups × 10 Inputs
Output Type
Relay Output
Number of Outputs
12 Points
Output Configuration
2 Groups × 6 Outputs
Input Voltage
24 VDC Nominal
Input Voltage Range
0–30 VDC
Input ON Voltage
15–30 VDC
Input OFF Voltage
0–5 VDC
Input Current
2–5.5 mA
Relay Output Voltage
5–265 VAC / 5–30 VDC
Relay Output Current
2.0 A Maximum per Point
Maximum Group Output Current
8 A per Group
Input Response Time
0.5 ms Basic
Output Response Time
10 ms Maximum
Isolation
Relay Output Isolation
Backplane Current Consumption
Approx. 100 mA at 5 VDC
LED Indicators
Individual I/O Status LEDs + OK LED
Mounting Type
VersaMax Carrier Mounted
Carrier Compatibility
IC200CHS Series
Dimensions
Approx. 110 × 66.8 × 50 mm
Weight
Approx. 0.25 kg
Recommended Companion Models
Model
Product Name
IC200CHS003C
VersaMax Connector-Style I/O Carrier Module
IC200PWR002G
VersaMax Expanded Power Supply Module
IC200CPU001
VersaMax CPU Controller Module
IC200MDL640J
VersaMax 24 VDC Discrete Input Module
Frequently Selected Alternatives
Model
Product Name
IC200MDD843
VersaMax 24 VDC Input 10 Point / Relay Output 6 Point Mixed Module
VersaMax 16 Point Input / 16 Point Protected Output Mixed Module
Where It Excels in Industrial Use
• Designed for GE VersaMax PLC systems, the IC200MDD840F combines 24 VDC discrete inputs with relay-based outputs in a single compact module, providing an efficient solution for industrial control applications requiring both signal monitoring and device switching.
• Suitable for manufacturing equipment, automated assembly systems, packaging machinery, conveyor applications, and process control installations where sensors and actuators must be managed through a distributed I/O architecture.
• Ideal for connecting switches, proximity sensors, pushbuttons, and other 24 VDC field devices while controlling contactors, relays, indicator lamps, and similar loads through relay outputs.
• Commonly used in VersaMax systems where reducing panel space, simplifying wiring, and combining multiple discrete functions into one module can improve overall automation efficiency.
Key Strengths at a Glance
• Integrates 20 points of 24 VDC positive logic inputs and 12 relay output points, allowing one module to handle both field signal acquisition and output control functions.
• Provides relay outputs rated up to 2.0 A per point, supporting a wide range of industrial loads including AC and DC devices.
• Features grouped input and output architecture with separate commons, helping engineers organize field wiring and simplify system maintenance.
• Includes individual I/O status LEDs and module diagnostics, improving troubleshooting speed during commissioning and routine operation.
Technical FAQs
1. What type of module is the GE IC200MDD840F?
The GE IC200MDD840F is a VersaMax discrete mixed I/O module combining 24 VDC digital inputs with relay outputs.
2. How many input points are available on the IC200MDD840F?
The module provides 20 discrete input points arranged in two groups of 10 inputs.
3. How many relay outputs does the IC200MDD840F provide?
The module provides 12 relay output points arranged in two groups of six outputs.
4. What type of input signals does the IC200MDD840F support?
The input section supports 24 VDC positive logic (sourcing) input signals from industrial field devices.
5. What output technology is used by the IC200MDD840F?
The module uses relay outputs capable of switching AC and DC loads.
6. What types of devices can be connected to the IC200MDD840F outputs?
The relay outputs can control devices such as contactors, relays, indicator lamps, and small industrial actuators.
7. Does the IC200MDD840F require external power for output loads?
Yes. Output loads require an external power source because the relay contacts only provide switching functionality.
8. What is the maximum relay output current capability?
Each relay output point supports up to 2.0 A depending on the connected load type.
9. Is the IC200MDD840F compatible with VersaMax carrier bases?
Yes. The module requires a compatible IC200CHS series VersaMax carrier base.
10. What should be checked before replacing an IC200MDD840F?
Engineers should verify carrier compatibility, field wiring, input voltage requirements, relay load ratings, and PLC configuration settings before installation.
monitoring and relay output control within a single compact module. It provides 20 channels of 24 VDC positive logic input and 12 relay output channels, helping reduce hardware requirements while maintaining flexible industrial connectivity.
