Brand:Schneider PLC Item No.:SR2E201FU Product Origin:France Product Dimensions:124.6 × 90 × 59.5 mm Product Weight:350 g Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider SR2E201FU Zelio Logic Compact Smart Relay is a practical automation controller designed for applications requiring reliable programmable control in a compact format. With 20 I/O points, AC power supply capability, relay outputs, and flexible programming options, it provides an efficient alternative for small automation systems.
Built for machine builders, facility automation engineers, and industrial users, this smart relay combines simple configuration with dependable performance. Its compact architecture makes it especially suitable for applications where installation space, operational reliability, and easy maintenance are key considerations.
Technical Specifications
Parameter
Specification
Brand
Schneider Electric
Model Number
SR2E201FU
Product Type
Compact Smart Relay Module
Series
Zelio Logic SR2
Power Supply Voltage
100...240 V AC
Discrete Inputs
12
Relay Outputs
8
Programming Method
Ladder Logic / Function Block Diagram
Memory Type
EEPROM Backup Memory
Display
Without Display
Clock Function
Integrated Clock
Operating Frequency
50/60 Hz
Operating Temperature
0...55°C
Mounting Type
DIN Rail Mounting
Dimensions (W × H × D)
124.6 × 90 × 59.5 mm
Weight
Approx. 350 g
Recommended Companion Models
Model
Product Name
SR2B121FU
Schneider Zelio Logic Compact Smart Relay Module
SR2B201BD
Schneider Zelio Logic Compact Smart Relay Module 24 V DC
• Small-Scale Automation Control
Designed for compact automation systems, the SR2E201FU provides reliable control functions for machines, equipment, and standalone applications where a full PLC system may be unnecessary.
• Building and Facility Automation
Suitable for lighting control, access systems, HVAC management, and other facility applications requiring flexible logic control and dependable operation.
• OEM Machine Applications
Ideal for equipment manufacturers developing customized machines that require simple programming, compact installation, and efficient control solutions.
• Industrial Control Upgrades
Helps modernize traditional relay-based systems by providing programmable logic functions with improved flexibility and easier maintenance.
Key Strengths at a Glance
• Flexible Programmable Control
The SR2E201FU supports ladder and function block programming, allowing engineers to create customized automation logic for different applications.
• Reliable Memory Protection
Built-in EEPROM memory provides long-term program backup capability, helping maintain system configuration after power interruptions.
• Compact Automation Solution
The compact design allows efficient installation in control cabinets where space optimization is important.
• Stable Relay Output Performance
Equipped with relay outputs suitable for controlling various industrial loads while maintaining dependable switching performance.
Technical FAQs
1. What type of controller is the Schneider SR2E201FU?
The Schneider SR2E201FU is a Zelio Logic compact smart relay designed for programmable automation and control applications.
2. Which programming methods are supported by this smart relay?
The SR2E201FU supports ladder programming and function block diagram programming for flexible application development.
3. How many inputs and outputs does the SR2E201FU provide?
The module provides 12 discrete inputs and 8 relay outputs for basic automation control tasks.
4. What power supply voltage does the SR2E201FU require?
The SR2E201FU operates with a rated supply voltage range of 100 to 240 V AC.
5. Does the SR2E201FU include internal program backup?
Yes, the smart relay includes EEPROM memory to retain user programs and support reliable recovery after power loss.
6. Can the SR2E201FU be programmed without advanced PLC experience?
Yes, the Zelio Logic platform is designed to simplify programming for engineers and technicians working on compact automation projects.
7. Does this model include a built-in display?
No, the SR2E201FU is a version without a local display and is configured through compatible programming tools.
8. What communication or expansion options are available for this relay family?
The Zelio Logic series supports compatible expansion and communication accessories depending on system requirements.
9. What industries commonly use the SR2E201FU?
It is commonly used in industrial machinery, building automation, water treatment equipment, and OEM control applications.
10. How does the SR2E201FU improve automation system efficiency?
The smart relay reduces control complexity by replacing multiple conventional relays with programmable logic functions in a compact device.
