Brand:Schneider PLC Item No.:SR2USB01 Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider SR2USB01 USB Programming Cable Module is a dedicated communication accessory designed for Zelio Logic smart relay systems. It provides a convenient connection between a PC and compatible smart relays, allowing engineers to efficiently program, configure, and monitor automation applications through Zelio Soft 2 software.
With its practical design and reliable communication capability, the SR2USB01 is widely used by automation engineers, OEM manufacturers, and maintenance teams working with compact control solutions. Its simple connection method helps streamline project development while improving service efficiency in industrial environments.
Technical Specifications
Parameter
Specification
Brand
Schneider Electric
Model Number
SR2USB01
Product Type
USB Programming Cable Module
Product Range
Zelio Logic
Accessory Type
Connecting Cable
Application
PC Connection for Smart Relay Programming
Compatible Software
Zelio Soft 2
Connector Type
USB
Cable Length
3 m
Compatible Devices
Zelio Logic SR2 / SR3 Smart Relays
Operating System Compatibility
Windows XP / Vista / Windows 7
Installation Method
Plug Connection
Dimensions
Approx. 3000 × 20 × 10 mm
Weight
Approx. 0.1 kg
Recommended Companion Models
Model
Product Name
SR2B121FU
Schneider Zelio Logic Compact Smart Relay Module
SR2E201FU
Schneider Zelio Logic Compact Smart Relay Module
SR3B261BD
Schneider Zelio Logic Modular Smart Relay Module
SR2MEM02
Schneider Zelio Logic EEPROM Memory Module
Frequently Selected Alternatives
Model
Product Name
SR2COM01
Schneider Zelio Logic Communication Interface Module
• Zelio Logic Programming and Commissioning
Designed for Schneider Electric Zelio Logic smart relays, the SR2USB01 provides a direct connection between the controller and PC, enabling efficient programming, configuration, and system commissioning.
• Automation Maintenance and Troubleshooting
The cable supports convenient access to smart relay programming environments, helping engineers update applications, diagnose control logic, and maintain automation systems more efficiently.
• OEM Equipment Development
Ideal for machine builders and system integrators who require a reliable programming interface during equipment development, testing, and repeated configuration processes.
• Industrial Control System Setup
Provides a practical connection solution for compact automation projects using Zelio Logic smart relays, reducing setup complexity during installation and service operations.
Key Strengths at a Glance
• Direct PC-to-Relay Communication
The SR2USB01 enables easy communication between Zelio Logic smart relays and computers through a dedicated USB connection for programming tasks.
• Optimized for Zelio Soft 2 Software
Designed to work with Zelio Soft 2 programming software, allowing engineers to create, modify, and transfer automation programs efficiently.
• Extended 3-Meter Cable Design
The 3-meter cable length provides greater flexibility when connecting control cabinets, workstations, and automation equipment during commissioning.
• Reliable Industrial Connectivity Accessory
Built as an original Zelio Logic accessory, the SR2USB01 provides stable communication performance for smart relay programming and service applications.
Technical FAQs
1. What is the primary function of the Schneider SR2USB01?
The SR2USB01 is a USB programming cable designed to connect Zelio Logic smart relays with a PC for programming and configuration tasks.
2. Which Schneider product families are compatible with the SR2USB01?
The SR2USB01 is designed for Schneider Electric Zelio Logic SR2 and SR3 smart relay product families.
3. Which software is used with the SR2USB01 for programming?
The SR2USB01 is compatible with Zelio Soft 2 software for developing and transferring smart relay applications.
4. What type of connection does the SR2USB01 provide?
The cable provides a USB connection interface between a computer and a compatible Zelio Logic smart relay.
5. Can the SR2USB01 be used for program transfer?
Yes, the SR2USB01 allows users to transfer application programs between Zelio Soft 2 software and compatible smart relays.
6. Does the SR2USB01 require a dedicated driver?
Yes, compatible USB driver installation may be required depending on the operating system and software environment used.
7. Is the SR2USB01 suitable for online monitoring functions?
Yes, when used with compatible Zelio Soft 2 environments, the cable supports programming and monitoring operations for supported smart relays.
8. What type of automation devices can be configured with the SR2USB01?
The cable is intended for Schneider Electric Zelio Logic smart relay systems used in compact automation applications.
9. Can the SR2USB01 replace traditional serial programming cables?
Yes, the SR2USB01 provides a USB-based programming connection designed for easier integration with modern computer systems.
10. How does the SR2USB01 improve engineering efficiency?
The cable simplifies programming access and reduces setup time during smart relay commissioning, maintenance, and application updates.
