Brand:Schneider PLC Item No.: SR3B101BD Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider SR3B101BD Modular Smart Relay Module is part of the Zelio Logic family, providing a practical automation solution for applications that require programmable control, compact installation, and reliable performance. With 10 I/O points, 24 V DC power supply support, built-in clock functionality, and an integrated display, it delivers a balanced solution for machine control and facility automation projects.
Designed for engineers, OEM manufacturers, and industrial system integrators, the SR3B101BD combines straightforward programming with flexible expansion capability. Its modular architecture makes it suitable for applications where efficient installation, easy maintenance, and dependable control performance are essential.
• Compact Automation Control Systems
The SR3B101BD is designed for small and medium automation applications requiring flexible logic control, reliable operation, and easy system configuration.
• Building and Facility Management
Suitable for lighting control, HVAC systems, access control, and other facility automation tasks where programmable control and monitoring are required.
• OEM Machine Control Solutions
Provides an efficient control platform for machine builders developing customized equipment with limited installation space and modular expansion requirements.
• Industrial Process Monitoring Applications
Supports applications requiring timing functions, analogue signal handling, and local operator interaction through an integrated display interface.
Key Strengths at a Glance
• Flexible Modular Architecture
The SR3B101BD offers a modular design that allows engineers to create adaptable control solutions for different automation requirements.
• Integrated Display and Clock Function
The built-in display and clock functions simplify local monitoring, parameter adjustment, and time-based automation operations.
• Reliable 24 V DC Operation
Designed for industrial control environments, the module provides stable 24 V DC power operation with protection features for dependable performance.
• Efficient Programming Capability
Supports ladder logic and function block programming, allowing engineers to develop customized automation sequences with reduced commissioning effort.
Technical FAQs
1. What type of product is the Schneider SR3B101BD?
The Schneider SR3B101BD is a Zelio Logic modular smart relay designed for programmable automation control applications.
2. What power supply voltage does the SR3B101BD require?
The SR3B101BD operates with a rated 24 V DC power supply and supports a supply voltage range suitable for industrial control systems.
3. How many inputs and outputs are available on the SR3B101BD?
The SR3B101BD provides 10 I/O points, including 6 discrete inputs and 4 relay outputs for automation control tasks.
4. Which programming methods are supported by this smart relay?
The module supports ladder programming and function block diagram programming for flexible application development.
5. Does the SR3B101BD include analogue input capability?
Yes, the SR3B101BD supports analogue input functions depending on the configured input channels and application requirements.
6. Does the SR3B101BD have internal memory backup?
Yes, the smart relay includes EEPROM memory backup technology to retain user programs during power interruptions.
7. Can the SR3B101BD be expanded with additional modules?
Yes, the modular Zelio Logic design allows compatible expansion accessories to extend system functionality.
8. What software is used to program the SR3B101BD?
The SR3B101BD can be programmed using Schneider Electric Zelio Soft programming software.
9. What type of outputs does the SR3B101BD provide?
The module uses relay outputs suitable for controlling various industrial loads within supported electrical specifications.
10. How does the SR3B101BD improve automation efficiency?
The module combines programmable logic, monitoring functions, and compact hardware design to simplify control system development and maintenance.
