Brand:Schneider PLC Item No.: SR3B262BD Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider SR3B262BD Modular Smart Relay Module is a high-performance control solution from the Zelio Logic family, designed for automation applications requiring greater flexibility than standard compact controllers. With 26 I/O points, 24 V DC operation, integrated display, clock functions, and transistor outputs, it provides an efficient platform for industrial equipment control and intelligent automation systems.
Built for OEM manufacturers, machine designers, and automation professionals, the SR3B262BD combines compact hardware with powerful programming features. Its modular structure, simple configuration process, and reliable memory protection make it suitable for applications where efficient installation, scalable control, and long-term operational stability are important.
• Advanced Automation Control Systems
The SR3B262BD provides expanded programmable control capability for industrial machines, equipment automation, and small-scale process systems requiring multiple digital and analogue signal inputs.
• OEM Machine Integration Projects
Designed for machine builders and system integrators, the module delivers flexible logic control, easy commissioning, and efficient integration into customized automation solutions.
• Building and Facility Automation
Suitable for lighting management, HVAC control, pump monitoring, and facility equipment automation where reliable scheduling and programmable operation are required.
• Industrial Monitoring Applications
Supports applications that require sensor input processing, timing functions, and output management through a compact DIN rail-mounted automation controller.
Key Strengths at a Glance
• Expanded 26 I/O Architecture
The SR3B262BD features 16 discrete inputs, 6 analogue inputs, and 10 transistor outputs, providing enhanced flexibility for larger smart relay applications.
• Fast and Flexible Programming Capability
Supports ladder logic and function block diagram programming, allowing engineers to develop customized automation sequences with efficient configuration workflows.
• Built-In Display and Clock Functionality
The integrated LCD display and clock functions simplify local monitoring, parameter adjustment, diagnostics, and time-based control operations.
• Reliable Data Backup Performance
Built-in EEPROM flash memory provides long-term program backup capability, helping simplify system recovery after unexpected power interruptions.
Technical FAQs
1. What type of device is the Schneider SR3B262BD?
The Schneider SR3B262BD is a Zelio Logic modular smart relay designed for programmable automation control applications.
2. What power supply voltage does the SR3B262BD require?
The SR3B262BD operates with a 24 V DC power supply and supports a supply voltage range suitable for industrial control environments.
3. How many inputs and outputs does the SR3B262BD provide?
The SR3B262BD provides 16 digital inputs, 6 analogue inputs, and 10 transistor outputs for flexible automation control.
4. Which programming methods are supported by the SR3B262BD?
The SR3B262BD supports ladder programming and function block diagram programming for developing customized control applications.
5. Does the SR3B262BD include an integrated display?
Yes, the module includes a local display with navigation functions for monitoring and configuration operations.
6. Can the SR3B262BD retain programs after power loss?
Yes, the module uses EEPROM flash memory technology to maintain stored application programs during power interruptions.
7. Is the SR3B262BD compatible with expansion modules?
Yes, the Zelio Logic modular platform supports compatible expansion accessories for extending system functionality.
8. What type of outputs does the SR3B262BD use?
The SR3B262BD uses transistor outputs designed for fast switching operations in compatible automation applications.
9. Which software is used to program the SR3B262BD?
The SR3B262BD can be programmed using Schneider Electric Zelio Soft programming software for ladder and function block development.
10. How does the SR3B262BD improve automation efficiency?
The SR3B262BD combines programmable logic, expanded I/O resources, and integrated diagnostic functions to simplify automation system development and maintenance.
