Brand:Schneider PLC Item No.:TM3BCEIP Product Origin:France Product Dimensions:125 x 104 x 74 mm Product Weight:0.1 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Product Introduction and Industrial Ethernet I/O Expansion Solution
The Schneider TM3BCEIP I/O Distributed Module is a professional automation communication component designed to improve the flexibility and scalability of modern control systems. It allows Modicon TM3 expansion modules to operate as distributed I/O stations within Ethernet-based industrial networks.
In modern manufacturing environments, centralized control architectures can create complicated wiring structures, especially when machines contain numerous sensors and actuators. Distributed I/O solutions provide a more efficient approach by moving signal processing closer to field devices.
The TM3BCEIP helps automation engineers create cleaner system layouts, reduce installation complexity, and improve machine modularity. It is suitable for applications ranging from standalone machines to larger industrial automation systems requiring reliable remote signal management.
With its compact design, flexible communication capability, and strong integration potential, the Schneider TM3BCEIP I/O Distributed Module is a valuable choice for machine builders and industrial automation professionals seeking efficient distributed control solutions.
Technical Specifications
Parameter
Description
Manufacturer
Schneider Electric
Model Number
TM3BCEIP
Product Type
I/O Distributed Module
Product Series
Modicon TM3
Module Function
Ethernet Distributed I/O Interface
Communication Interface
Industrial Ethernet
Compatible Modules
Modicon TM3 Expansion Modules
Network Application
Distributed Automation Systems
Mounting Method
DIN Rail Installation
Connection Type
Ethernet Interface and Terminal Connection
Protection Rating
IP20
Rated Supply Voltage
24 VDC
Dimensions
125 × 104 × 74 mm
Weight
0.10 kg (0.22 lb)
Application Environment
Industrial Automation and Distributed Control Systems
Recommended Related Models
Model
Product Type
Schneider TM3BCEIP
I/O Distributed Module
Schneider TM3BCEIPT
Ethernet Bus Coupler Module
Schneider TM3XREC1
Receiver Module
Schneider TM3XREC3
Receiver Module
Schneider TM3AI4G
Analog Input Module
Popular Related Models
Model
Product Type
Schneider TM3DI16K
Digital Input Module
Schneider TM3DQ16T
Digital Output Module
Schneider TM3DQ16R
Relay Output Module
Schneider TM3AI4G
Analog Input Module
Schneider TM3AQ2
Analog Output Module
Schneider BMXP342020
Modicon M340 CPU Module
Schneider BMXNOC0401
Ethernet Communication Module
Schneider BMXDDO1602
Modicon X80 Digital Output Module
The Schneider TM3BCEIP I/O Distributed Module is a reliable industrial automation communication solution designed for flexible remote I/O deployment and Ethernet-based control architectures. With compact dimensions, efficient network integration, and scalable expansion capability, it helps improve system organization and supports modern industrial automation applications.
