Brand:Schneider PLC Item No.:TM2DRA16RT Product Origin:France Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM2DRA16RT Relay Output Module is a high-density digital expansion solution designed for Schneider Electric automation systems requiring additional relay switching capacity. Featuring 16 relay output channels, the module enables flexible control of industrial equipment such as contactors, valves, lighting systems, and auxiliary machinery.
Built for machine automation and industrial control applications, the TM2DRA16RT combines reliable relay technology with a compact modular structure. Its robust switching capability, convenient terminal design, and compatibility with Schneider controller platforms make it an effective choice for expanding automation systems while maintaining efficient cabinet layouts.
Technical Specifications
Parameter
Specification
Brand
Schneider Electric
Model Number
TM2DRA16RT
Product Type
Relay Output Module
Product Range
Modicon TM2
Module Type
Digital Output Expansion Module
Output Channels
16
Output Type
Relay
Contact Type
1 NO Contact per Output
Output Common Groups
2
Maximum Current per Channel
2 A
Maximum Current per Common
8 A
Rated Voltage
24 V DC / 240 V AC
Minimum Switching Current
0.1 mA at 0.1 V DC
Contact Resistance
≤45 mΩ
Channel Isolation
1500 V for 1 minute
Isolation to Internal Logic
2300 V for 1 minute
Response Time ON
≤10 ms
Response Time OFF
≤5 ms
Mechanical Durability
20,000,000 cycles
Electrical Durability
100,000 cycles
Connection Type
Removable Screw Terminal Block
Mounting Type
DIN Rail Mounting
Protection Rating
IP20
Compatible Platforms
Modicon M238 / Twido / Advantys OTB
Dimensions (W × H × D)
Approx. 23.65 × 90 × 81.3 mm
Weight
Approx. 180 g
Recommended Companion Models
Model
Product Name
TM2DMM8DRT
Schneider Modicon TM2 Digital Mixed I/O Module
TM2DRA8RT
Schneider Modicon TM2 Relay Output Module
TM2DDO16TK
Schneider Modicon TM2 Transistor Output Module
TM2AMI4LT
Schneider Modicon TM2 Analog Input Module
Frequently Selected Alternatives
Model
Product Name
TM3DQ16R
Schneider Modicon TM3 Relay Output Module
TM3DQ16T
Schneider Modicon TM3 Transistor Output Module
BMXDRA0805
Schneider Modicon X80 Relay Output Module
TM2DRA8RT
Schneider Modicon TM2 Relay Output Module
Where It Excels in Industrial Use
• Industrial Machine Control Expansion
The TM2DRA16RT provides additional relay output capacity for Schneider Electric controller platforms, allowing machines and automation systems to manage more actuators, contactors, valves, and auxiliary devices.
• Discrete Load Switching Applications
Designed for applications requiring reliable ON/OFF control, the module is suitable for switching motors, lamps, solenoid valves, alarms, and other electrical loads within industrial environments.
• OEM Equipment Automation
The module is widely suited for compact machine builders who need flexible relay expansion while maintaining a modular control cabinet design.
• Distributed Control System Integration
With its removable screw terminal connection and modular architecture, the TM2DRA16RT supports efficient installation and maintenance in automation panels.
Key Strengths at a Glance
• 16-Channel Relay Output Expansion
The TM2DRA16RT offers 16 relay output channels with normally open contacts, providing expanded switching capability for Modicon controller systems.
• Flexible Load Compatibility
Each relay output supports up to 2 A switching current, making the module suitable for a wide range of industrial control applications involving AC and DC loads.
• Reliable Mechanical Switching Performance
The relay-based output design provides electrical isolation and dependable switching for applications where direct transistor outputs may not be suitable.
• Simple Cabinet Installation
The removable screw terminal block design simplifies wiring, replacement, and maintenance operations during system integration.
Technical FAQs
1. What type of product is the Schneider TM2DRA16RT?
The Schneider TM2DRA16RT is a digital relay output expansion module designed for Modicon controller systems.
2. How many output channels does the TM2DRA16RT provide?
The TM2DRA16RT provides 16 relay output channels for controlling external devices.
3. What type of outputs are used on the TM2DRA16RT?
The module uses relay outputs with one normally open contact per channel.
4. What is the maximum current rating of each output channel?
Each relay output channel supports a maximum switching current of 2 A.
5. Which controller families are compatible with the TM2DRA16RT?
The module is designed for Schneider Electric Modicon controller platforms including Modicon M238 systems and compatible expansion architectures.
6. Does the TM2DRA16RT provide analogue signal processing?
No, the TM2DRA16RT is a discrete relay output module and does not process analogue input or output signals.
7. What connection method is used by the TM2DRA16RT?
The module uses a removable screw terminal block for field wiring connections.
8. How many common terminals are available on the TM2DRA16RT?
The output channels are arranged into two common groups for flexible wiring configurations.
9. Can the TM2DRA16RT switch both AC and DC loads?
Yes, the relay contacts support switching applications using both AC and DC load circuits within specified ratings.
10. What software environment is used to configure the TM2DRA16RT?
The module is configured through the programming environment associated with the connected Schneider Electric controller platform.
