Brand:Schneider PLC Item No.:TM3AM6G Product Origin:France Product Dimensions:108 × 7.2 × 7.2 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM3AM6G Analog I/O Expansion Module is a versatile expansion component from the Modicon TM3 family, designed to enhance controller capabilities with additional analogue measurement and control functions. Featuring four analogue inputs and two analogue outputs, it enables seamless integration of sensors, transmitters, and analogue-controlled devices into modern automation systems.
Engineered for machine builders, OEM manufacturers, and industrial system integrators, the TM3AM6G combines flexible signal handling, reliable performance, and compact installation. Its support for common industrial voltage and current signals makes it an effective choice for applications requiring accurate monitoring and precise analogue control.
Technical Specifications
Parameter
Specification
Brand
Schneider Electric
Model Number
TM3AM6G
Product Type
Analog I/O Expansion Module
Product Range
Modicon TM3
Module Type
Analog Mixed Input/Output Module
Compatible Controllers
Modicon M221 / M241 / M251 / M262
Supply Voltage
24 V DC
Analog Inputs
4
Analog Outputs
2
Input Signal Types
0...10 V, -10...+10 V, 0...20 mA, 4...20 mA
Output Signal Types
0...10 V, -10...+10 V, 0...20 mA, 4...20 mA
Input Resolution
12 bits / 11 bits + sign
Output Resolution
12 bits / 11 bits + sign
Input Impedance
≥1 MΩ (Voltage), ≤50 Ω (Current)
Output Load
≥1 kΩ (Voltage), ≤300 Ω (Current)
Conversion Time
1 ms + 1 ms per channel + controller cycle
Stabilization Time
1 ms
Cable Type
Twisted shielded pair
Maximum Cable Length
30 m
Connection Type
Removable Spring Terminal Block
Mounting Type
DIN Rail Mounting
Protection Rating
IP20
Operating Temperature
-10...55°C
Dimensions (W × H × D)
Approx. 23.65 × 90 × 73.3 mm
Weight
Approx. 100 g
Recommended Companion Models
Model
Product Name
TM241CE40T
Schneider Modicon M241 Logic Controller
TM3DQ16R
Schneider Modicon TM3 Relay Output Module
TM3DI16K
Schneider Modicon TM3 Digital Input Module
TM3TI4
Schneider Modicon TM3 Temperature Input Module
Frequently Selected Alternatives
Model
Product Name
TM3AM6
Schneider Modicon TM3 Analog I/O Expansion Module
TM3AI8
Schneider Modicon TM3 Analog Input Module
TM3AQ4
Schneider Modicon TM3 Analog Output Module
TM2AMM6HT
Schneider Modicon TM2 Analog Mixed I/O Module
Where It Excels in Industrial Use
• Machine Automation Signal Expansion
The TM3AM6G expands Schneider Electric controller systems with additional analogue input and output channels, making it suitable for machines requiring sensor monitoring and actuator regulation within a compact control architecture.
• Process Monitoring and Control Applications
Designed for handling voltage and current signals, the module supports applications such as pressure monitoring, flow control, temperature transmitters, and proportional device control in industrial environments.
• OEM Equipment Integration
The compact Modicon TM3 design allows machine builders to add analogue functionality to M221, M241, M251, and M262 controller platforms without major cabinet redesigns.
• Flexible Industrial Automation Systems
With multiple signal ranges and spring terminal connections, the TM3AM6G provides a practical solution for automation projects requiring reliable analogue data acquisition and output control.
Key Strengths at a Glance
• Six-Channel Analog Expansion Capability
The TM3AM6G integrates four analogue inputs and two analogue outputs, providing a balanced solution for systems requiring both measurement and control functions.
• Wide Signal Compatibility
The module supports 0...10 V, -10...+10 V, 0...20 mA, and 4...20 mA signal ranges for both input and output channels, improving compatibility with industrial sensors and actuators.
• 12-Bit Signal Resolution
With 12-bit analogue conversion capability, the TM3AM6G delivers accurate signal processing for demanding automation and control applications.
• Space-Saving Spring Terminal Design
The removable spring terminal block simplifies wiring operations while supporting efficient installation and maintenance inside industrial control cabinets.
Technical FAQs
1. What type of product is the Schneider TM3AM6G?
The Schneider TM3AM6G is a Modicon TM3 analogue mixed I/O expansion module that combines analogue input and output functions in a single unit.
2. How many analogue inputs does the TM3AM6G provide?
The TM3AM6G provides four analogue input channels for voltage and current signal measurement.
3. How many analogue outputs are available on the TM3AM6G?
The module provides two analogue output channels for controlling external analogue devices.
4. Which signal types are supported by the TM3AM6G inputs?
The analogue inputs support 0...10 V, -10...+10 V, 0...20 mA, and 4...20 mA signal types.
5. Which signal types are supported by the TM3AM6G outputs?
The analogue outputs support 0...10 V, -10...+10 V, 0...20 mA, and 4...20 mA signal types.
6. What resolution does the TM3AM6G provide?
The TM3AM6G provides 12-bit resolution, or 11 bits plus sign depending on the configured signal range.
7. Which Schneider controller families are compatible with the TM3AM6G?
The TM3AM6G is compatible with Modicon M221, M241, M251, and M262 controller platforms.
8. Does the TM3AM6G provide sensor loop power?
No, the TM3AM6G does not provide loop power for current-type sensors and external power must be supplied when required.
9. What connection method is used by the TM3AM6G?
The TM3AM6G uses a removable spring terminal block for field wiring connections.
10. Which software is used to configure the TM3AM6G?
The TM3AM6G is configured through Schneider Electric EcoStruxure Machine Expert software when used with compatible Modicon controllers.
