Brand:Schneider PLC Item No.:TM3DQ16TG Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM3DQ16TG Digital Output Module is a compact and reliable expansion solution from the Modicon TM3 family, designed to increase digital output capacity for industrial automation systems. Featuring 16 transistor source outputs, it provides efficient control of 24 VDC field devices commonly used in machine automation and production environments.
Engineered for OEM manufacturers, system integrators, and automation professionals, the TM3DQ16TG combines fast switching performance, robust protection functions, and flexible spring terminal wiring. Its seamless integration with Modicon M2xx controller platforms makes it a practical choice for scalable machine control applications.
• High-Density Machine Output Control
The TM3DQ16TG provides 16 transistor output channels for controlling industrial devices such as solenoid valves, contactors, indicator lamps, relays, and other 24 VDC automation components.
• Fast Switching Automation Applications
With transistor-based source outputs and fast response performance, the module is suitable for applications requiring frequent switching operations, including packaging machines, assembly systems, and production equipment.
• OEM Machine Expansion Projects
Designed for Modicon M221, M241, M251, and M262 controller platforms, the TM3DQ16TG allows machine builders to expand digital output capacity while maintaining a compact cabinet layout.
• Reliable Industrial Control Panels
The spring terminal connection design provides efficient wiring and simplified maintenance, making the module suitable for modern industrial control cabinets where installation flexibility is important.
Key Strengths at a Glance
• 16-Channel Transistor Output Design
The TM3DQ16TG features 16 source transistor outputs with 24 VDC operation, providing reliable switching performance for industrial automation systems.
• High-Speed Output Response
The transistor output architecture delivers fast switching with approximately 450 μs ON and OFF response times, supporting dynamic machine control requirements.
• Integrated Output Protection
The module includes overload protection, short-circuit protection, and reverse polarity protection to improve operational reliability in industrial environments.
• Flexible Spring Terminal Installation
The removable spring terminal block allows quick wiring, replacement, and maintenance while reducing installation time inside automation cabinets.
Technical FAQs
1. What type of product is the Schneider TM3DQ16TG?
The Schneider TM3DQ16TG is a Modicon TM3 digital output expansion module with 16 transistor source outputs designed for industrial automation systems.
2. How many output channels does the TM3DQ16TG provide?
The TM3DQ16TG provides 16 independent digital output channels.
3. What output technology does the TM3DQ16TG use?
The module uses transistor outputs with source (PNP) logic, providing current delivery to connected field devices.
4. What is the rated output voltage of the TM3DQ16TG?
The TM3DQ16TG operates with a rated output voltage of 24 VDC.
5. What is the maximum output current per channel?
Each output channel supports a rated current of 0.5 A.
6. Which controller families are compatible with the TM3DQ16TG?
The module is compatible with Modicon M221, M241, M251, and M262 controllers.
7. Does the TM3DQ16TG support short-circuit protection?
Yes, the module provides short-circuit and overload protection with automatic recovery capability after fault conditions.
8. What type of terminal connection does the TM3DQ16TG use?
The TM3DQ16TG uses a removable spring terminal block for field wiring connections.
9. What switching speed can the TM3DQ16TG achieve?
The module provides switching times of approximately 450 μs for both output activation and deactivation.
10. Which software environment is used to configure the TM3DQ16TG?
The module is configured through Schneider Electric EcoStruxure Machine Expert software when used with compatible Modicon controllers.
