Brand:Schneider PLC Item No.:TM3DQ16TK Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM3DQ16TK Digital Output Module is a reliable expansion component from the Modicon TM3 family, designed to increase digital output capability for compact and advanced automation systems. Featuring 16 transistor source outputs, it provides efficient 24 VDC signal control for industrial actuators, indicators, and automation devices.
Built for OEM manufacturers, machine builders, and industrial automation engineers, the TM3DQ16TK combines fast switching performance, integrated protection features, and a compact modular structure. Its compatibility with multiple Modicon controller platforms makes it a practical choice for scalable machine control solutions.
Technical Specifications
Parameter
Specification
Brand
Schneider Electric
Model Number
TM3DQ16TK
Product Type
Digital Output Module
Product Range
Modicon TM3
Module Type
Transistor Output Expansion Module
Compatible Controllers
Modicon M221 / M241 / M251 / M262
Number of Outputs
16
Output Type
Transistor
Logic Type
Source (PNP)
Rated Output Voltage
24 VDC
Output Voltage Range
19.2...28.8 VDC
Rated Output Current
0.1 A per channel
Total Output Current
2 A per group
Output Groups
1 common line for 16 outputs
Voltage Drop
Maximum 0.4 VDC
Leakage Current
Maximum 0.1 mA
Turn-On Time
Approx. 450 μs
Turn-Off Time
Approx. 450 μs
Switching Frequency
Maximum 100 Hz
Short-Circuit Protection
Yes
Overload Protection
Yes
Reverse Polarity Protection
Yes
Automatic Recovery
Supported
Isolation Voltage
500 VAC between output and internal logic
Connection Type
HE10 (MIL 20) Connector
Status Indicator
Green LED per channel
Mounting Type
DIN Rail Mounting
Protection Rating
IP20
Operating Temperature
-10...55°C
Dimensions (W × H × D)
Approx. 23.65 × 90 × 70 mm
Weight
Approx. 165 g
Recommended Companion Models
Model
Product Name
TM241CE40T
Schneider Modicon M241 Logic Controller
TM3DI16K
Schneider Modicon TM3 16-Channel Digital Input Module
• Compact Machine Output Expansion
The TM3DQ16TK provides 16 transistor source outputs for expanding digital control capacity in Schneider Electric Modicon automation systems, making it suitable for controlling valves, indicator lamps, small relays, and other 24 VDC field devices.
• High-Speed Discrete Control Applications
With transistor-based switching technology and fast response characteristics, the module supports automation equipment requiring frequent ON/OFF operations, including assembly machines, packaging systems, and material handling equipment.
• OEM Equipment Automation Projects
The TM3DQ16TK is designed for Modicon M221, M241, M251, and M262 controller platforms, providing machine builders with a flexible way to increase digital output points while maintaining a compact cabinet design.
• Modular Industrial Control Systems
Its HE10 connector interface and simple expansion structure allow efficient integration into automation panels where space saving, quick connection, and reliable operation are important.
Key Strengths at a Glance
• 16-Point Transistor Output Capacity
The TM3DQ16TK features 16 source transistor outputs with 24 VDC operation, providing reliable digital switching for industrial automation devices.
• Fast Switching Performance
The transistor output design provides approximately 450 μs ON and OFF response times, making it suitable for applications requiring rapid control actions.
• Integrated Protection Functions
The module includes short-circuit protection, overload protection, reverse polarity protection, and automatic recovery functions to improve system reliability.
• Individual Channel Status Monitoring
Each output channel is equipped with a green LED indicator, allowing technicians to quickly identify operating conditions during commissioning and maintenance.
Technical FAQs
1. What type of module is the Schneider TM3DQ16TK?
The Schneider TM3DQ16TK is a Modicon TM3 digital output expansion module featuring 16 transistor source outputs for 24 VDC automation applications.
2. How many output channels does the TM3DQ16TK provide?
The TM3DQ16TK provides 16 independent digital output channels.
3. What output technology does the TM3DQ16TK use?
The module uses transistor output technology with positive logic source (PNP) operation.
4. What is the rated output voltage of the TM3DQ16TK?
The TM3DQ16TK operates with a rated output voltage of 24 VDC and supports an operating range of 19.2 to 28.8 VDC.
5. What is the maximum output current per channel?
Each output channel supports a maximum rated current of 0.1 A.
6. Which Schneider controller families are compatible with the TM3DQ16TK?
The TM3DQ16TK is compatible with Modicon M221, M241, M251, and M262 controller platforms.
7. Does the TM3DQ16TK provide short-circuit protection?
Yes, the module includes short-circuit protection with automatic rearming after fault conditions are cleared.
8. What type of connector is used by the TM3DQ16TK?
The TM3DQ16TK uses an HE10 (MIL 20) connector for output wiring connections.
9. What is the response time of the TM3DQ16TK outputs?
The module provides approximately 450 μs response time for both output activation and deactivation.
10. What software environment is used with the TM3DQ16TK?
The TM3DQ16TK is configured through Schneider Electric EcoStruxure Machine Expert when integrated with compatible Modicon controllers.
