Brand:Schneider PLC Item No.:TM5ACBM12 Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5ACBM12 Bus Base Module is a specialized foundation component for the Modicon TM5 modular I/O platform, designed to support AC electronic modules in advanced industrial automation applications. With its black-coded architecture, it provides the correct electrical interface for integrating AC input modules and relay output modules into distributed control systems.
Built for OEM machine builders, automation engineers, and system integrators, the TM5ACBM12 delivers a reliable and flexible approach to expanding industrial I/O capability. Its modular construction helps simplify system design, improve installation efficiency, and maintain the scalability required for modern automation projects.
Technical Specifications
Parameter
Specification
Brand
Schneider Electric
Model Number
TM5ACBM12
Product Type
Bus Base Module
Product Range
Modicon TM5
Module Type
AC Module Bus Base
Compatible Controllers
Modicon M258 / LMC058
Compatible Modules
AC Input Modules / Relay Output Modules
Housing Color
Black
Compatible Voltage Class
100...240 VAC Applications
Relay Module Compatibility
30 VDC / 230 VAC Relay Output Modules
I/O Power Segment
24 VDC Pass-Through
Address Setting Function
Not Supported
TM5 Power Bus Current Consumption
26 mA
Maximum Power Dissipation
0.13 W
Mounting Type
TM5 Modular Slice Installation
Protection Rating
IP20
Operating Temperature
-10...55°C
Storage Temperature
-25...70°C
Dimensions (W × H × D)
Approx. 12.5 × 90 × 70 mm
Weight
Approx. 20 g
Recommended Companion Models
Model
Product Name
TM5SDI12D
Schneider Modicon TM5 12-Channel Digital Input Module
TM5SDO12T
Schneider Modicon TM5 12-Channel Digital Output Module
Schneider Modicon TM5 24 VDC Address Setting Bus Base Module
TM5ACBM01R
Schneider Modicon TM5 24 VDC PDM and Receiver Bus Base Module
TM5ACBM05R
Schneider Modicon TM5 24 VDC Address Setting Bus Base Module
Where It Excels in Industrial Use
• AC Module Integration in Modular I/O Systems
The TM5ACBM12 is designed specifically for Modicon TM5 AC electronic modules, providing the required bus base structure for integrating AC input and output modules into distributed automation systems.
• Industrial Machine Power Control Applications
The module is suitable for automation equipment using AC field devices, including industrial machines, production lines, and OEM systems that require reliable integration of 100...240 VAC discrete input modules or 30 VDC/230 VAC relay output modules.
• Distributed I/O Architecture Expansion
Used within Modicon TM5 modular I/O configurations, the TM5ACBM12 helps create flexible and scalable remote I/O islands for complex automation systems requiring mixed voltage signal handling.
• Efficient Control Cabinet Design
The compact black bus base design simplifies installation of compatible AC modules while maintaining the modular structure and maintenance advantages of the TM5 platform.
Key Strengths at a Glance
• Dedicated AC Module Bus Base
The TM5ACBM12 is a black TM5 bus base specifically developed for AC electronic modules, ensuring correct electrical compatibility between the bus base, electronic module, and terminal block.
• 24 VDC I/O Power Segment Pass-Through
The module supports 24 VDC I/O power segment pass-through, allowing organized power distribution within TM5 slice configurations.
• Supports High-Voltage AC Applications
The TM5ACBM12 is required when using TM5 electronic modules with relay outputs rated for 30 VDC / 230 VAC, providing a safe and compatible mounting base for these applications.
• Reliable Modular System Compatibility
The bus base works with Modicon M258 and LMC058 controller platforms, enabling flexible expansion of industrial automation systems.
Technical FAQs
1. What type of product is the Schneider TM5ACBM12?
The Schneider TM5ACBM12 is a Modicon TM5 bus base module designed for AC electronic modules within a modular I/O system.
2. What is the main function of the TM5ACBM12?
The TM5ACBM12 provides the mechanical mounting structure and electrical connection interface required for compatible TM5 AC input and output electronic modules.
3. Which controller platforms are compatible with the TM5ACBM12?
The TM5ACBM12 is designed for Modicon TM5 systems commonly used with Modicon M258 and LMC058 controller platforms.
4. What type of modules require the TM5ACBM12?
The TM5ACBM12 is required for compatible AC electronic modules, including 100...240 VAC discrete input modules and 30 VDC/230 VAC relay output modules.
5. What color identification does the TM5ACBM12 use?
The TM5ACBM12 uses a black housing identification for compatibility with AC electronic modules in the TM5 system.
6. Is the TM5ACBM12 an input or output module?
No. The TM5ACBM12 is a bus base component and does not directly process input or output signals.
7. Does the TM5ACBM12 require software configuration?
No. The TM5ACBM12 is a hardware mounting and connection component and does not require independent software configuration.
8. Can the TM5ACBM12 be combined with white or gray TM5 bus bases?
No. TM5 slice components must maintain matching color compatibility to ensure correct electrical and mechanical integration.
9. What is the power consumption of the TM5ACBM12?
The TM5ACBM12 has a TM5 power bus current consumption of approximately 26 mA with maximum power dissipation of 0.13 W.
10. What mounting method is used for the TM5ACBM12?
The TM5ACBM12 is installed as part of a Modicon TM5 modular slice assembly inside industrial control cabinets.
