Brand:Schneider PLC Item No.:TSXDMY28RFK Product Origin:France Product Dimensions:260 x 180 x 55 mm Product Weight:0.49 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Product Introduction and Compact Digital Automation Expansion Solution
The Schneider TSXDMY28RFK Discrete I/O Module is a professional automation component developed for expanding digital control functions in Modicon Premium PLC systems. It provides a practical solution for applications that require both field signal monitoring and output device control.
Modern industrial machines typically include numerous sensors, switches, and actuators. Managing these devices efficiently requires flexible I/O architecture that can support increasing automation demands. The TSXDMY28RFK helps engineers achieve this by combining multiple digital functions into a single expansion module.
The module supports reliable communication between PLC controllers and field equipment, making it suitable for machine automation, production line improvements, and industrial system upgrades. Its integrated design helps reduce cabinet space requirements while maintaining dependable control performance.
For automation professionals, the Schneider TSXDMY28RFK Discrete I/O Module offers a practical approach to improving PLC capability, simplifying system structure, and supporting efficient industrial operations.
Technical Specifications
Parameter
Description
Manufacturer
Schneider Electric
Model Number
TSXDMY28RFK
Product Type
Discrete I/O Module
Product Series
Modicon Premium
Module Function
Digital Input and Output Expansion
Digital Inputs
16 Channels
Digital Outputs
12 Channels
Input Type
Digital Input
Output Type
Relay Output
Rated Voltage
24 VDC
Application
PLC Signal Monitoring and Device Control
Compatible System
Modicon Premium PLC Platform
Mounting Method
PLC Rack Installation
Connection Type
Terminal Connector
Dimensions
260 × 180 × 55 mm
Weight
0.49 kg (1.08 lb)
Application Environment
Industrial Automation and PLC Control Systems
Recommended Related Models
Model
Product Type
Schneider TSXDMY28RFK
Discrete I/O Module
Schneider TSXDMY28FK
Mixed Digital I/O Module
Schneider TSXDEY16A5
Discrete Input Module
Schneider TSXDSY16T2
Discrete Output Module
Schneider TSXCTZ2AA
Counter Module
Popular Related Models
Model
Product Type
Schneider BMXDDM16022
Mixed Digital I/O Module
Schneider BMXDDI1602
Digital Input Module
Schneider BMXDDO1602
Digital Output Module
Schneider BMXAMI0810
Analog Input Module
Schneider BMXAMO0210
Analog Output Module
Schneider BMXP342020
Modicon M340 CPU Module
Schneider BMXNOC0401
Ethernet Communication Module
Schneider TM3DM32R
Hybrid I/O Module
The Schneider TSXDMY28RFK Discrete I/O Module is a dependable industrial automation expansion component designed for applications requiring flexible digital input monitoring and output control. With integrated I/O functionality, reliable signal handling, and Modicon Premium compatibility, it helps improve automation system performance and supports efficient industrial control solutions.
