Brand:Schneider PLC Item No.:TM5ACBM3FS Product Origin:France Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.3 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5ACBM3FS Safety Bus Base Module is a specialized component within the Modicon TM5 safety automation platform, designed to provide a secure and dependable connection foundation for safety-related I/O modules. With its safety-coded structure and 24 VDC I/O power segment interconnection, it supports the development of flexible safety control systems for demanding industrial applications.
Built for machine builders, OEM manufacturers, and automation system integrators, the TM5ACBM3FS combines reliable safety architecture, modular expansion capability, and efficient cabinet integration. Its dedicated safety design makes it a valuable solution for applications requiring high-performance machine protection and dependable safety signal management.
Technical Specifications
Parameter
Specification
Brand
Schneider Electric
Model Number
TM5ACBM3FS
Product Type
Safety Bus Base Module
Product Range
Modicon TM5
Module Type
Safety-Coded Bus Base
Compatible Modules
TM5 Safety I/O Modules
Compatible Controllers
Modicon M258 / LMC058 Safety Systems
Housing Color
Red
Rated Supply Voltage
24 VDC
I/O Power Segment
24 VDC Pass-Through
Safety Coding
Supported
Internal I/O Supply
Interconnected
Power Consumption
0.13 W
Protection Rating
IP20
Mounting Type
TM5 Modular Slice Installation
Operating Temperature
0...55°C
Storage Temperature
-25...70°C
Dimensions (W × H × D)
Approx. 12.5 × 90 × 70 mm
Weight
Approx. 58 g
Recommended Companion Models
Model
Product Name
TM5SDM4DTRFS
Schneider Modicon TM5 Safety Digital Mixed I/O Module
TM5SAI4AFS
Schneider Modicon TM5 Safety Analog Input Module
TM5SDI12DFS
Schneider Modicon TM5 Safety Digital Input Module
TM5SPS10FS
Schneider Modicon TM5 Safety Power Distribution Module
Frequently Selected Alternatives
Model
Product Name
TM5ACBM4FS
Schneider Modicon TM5 Safety Bus Base Module with Isolated I/O Power Segment
TM5ACBM15
Schneider Modicon TM5 24 VDC Address Setting Bus Base Module
TM5ACBM11
Schneider Modicon TM5 24 VDC Electronic Module Bus Base Module
TM5ACBM05R
Schneider Modicon TM5 24 VDC Address Setting Bus Base Module
Where It Excels in Industrial Use
• Safety Automation System Expansion
The TM5ACBM3FS is designed as a safety bus base for Modicon TM5 Safety I/O modules, providing a secure and reliable foundation for building safety-related distributed I/O systems in industrial automation environments.
• Machine Safety Control Applications
The module is ideal for safety-focused machinery such as packaging systems, robotic workstations, assembly equipment, and production lines where dependable safety I/O integration is essential.
• Modular Safety I/O Architecture
The TM5ACBM3FS enables flexible expansion of TM5 safety modules by providing a dedicated safety-coded connection base with interconnected internal I/O power supply distribution.
• Industrial Control Cabinet Optimization
With its compact IP20 modular design, the module helps engineers create organized safety control architectures while reducing installation complexity and improving system maintainability.
Key Strengths at a Glance
• Safety-Coded Bus Base Structure
The TM5ACBM3FS features a safety-coded design specifically developed for Modicon TM5 Safety I/O modules, ensuring correct module matching within safety-related configurations.
• 24 VDC Safety I/O Power Segment Pass-Through
The module supports internal I/O supply interconnection, allowing efficient distribution of the 24 VDC I/O power segment across compatible safety slices.
• Dedicated TM5 Safety Module Compatibility
The TM5ACBM3FS is engineered for TM5 safety electronic modules and supports reliable integration within Modicon M258 and LMC058 safety automation platforms.
• Reliable Industrial Safety Design
The red-coded bus base simplifies identification of safety components and helps maintain proper configuration of safety-related modular I/O systems.
Technical FAQs
1. What type of module is the Schneider TM5ACBM3FS?
The Schneider TM5ACBM3FS is a Modicon TM5 safety bus base module designed for safety-related TM5 I/O modules.
2. What is the main function of the TM5ACBM3FS?
The TM5ACBM3FS provides the mechanical mounting structure and electrical bus connection required for compatible TM5 Safety I/O modules.
3. Is the TM5ACBM3FS an input or output module?
No. The TM5ACBM3FS is a bus base component and does not directly process field input or output signals.
4. Which Schneider product family does the TM5ACBM3FS belong to?
The TM5ACBM3FS belongs to the Modicon TM5 modular I/O product family.
5. What type of modules can be installed with the TM5ACBM3FS?
The TM5ACBM3FS is designed for compatible Modicon TM5 Safety I/O electronic modules.
6. What voltage rating does the TM5ACBM3FS support?
The TM5ACBM3FS is designed for a 24 VDC safety I/O power environment.
7. What is the purpose of the safety coding feature?
The safety coding feature helps ensure that only compatible safety-related TM5 components are assembled together within the system.
8. Does the TM5ACBM3FS require software configuration?
No. The TM5ACBM3FS is a hardware connection component and does not require independent software configuration.
9. What color identification does the TM5ACBM3FS use?
The TM5ACBM3FS uses a red housing color to identify its safety-related TM5 function.
10. What protection rating does the TM5ACBM3FS provide?
The TM5ACBM3FS provides an IP20 protection rating for installation inside suitable industrial control cabinets.
