Brand:Schneider PLC Item No.:TM5ACBN1 Product Origin:France Product Dimensions:202 × 21 × 261 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5ACBN1 Bus Base Module is a dedicated communication foundation component within the Modicon TM5 modular I/O platform. Designed for fieldbus interface assemblies, it provides the required mechanical and electrical connection between communication interface modules, interface power distribution modules, and the TM5 system architecture.
Engineered for OEM machine builders, automation engineers, and industrial system integrators, the TM5ACBN1 delivers a reliable solution for expanding distributed control systems with advanced communication capability. Its compact design, 24 VDC support, and compatibility with multiple TM5 interface modules make it a practical choice for modern automation applications requiring stable field communication and flexible system expansion.
Technical Specifications
Parameter
Specification
Brand
Schneider Electric
Model Number
TM5ACBN1
Product Type
Bus Base Module
Product Range
Modicon TM5
Module Type
Fieldbus Interface Bus Base
Compatible Controllers
Modicon M258 / LMC058 / LMC078
Compatible Modules
TM5NCO1, TM5NS31, TM5SPS3
Function
Fieldbus Interface Module Mounting and Power Interface
Housing Color
White
Rated Supply Voltage
24 VDC
Protection Rating
IP20
Included Accessories
2 Protective Plates
Mounting Type
DIN Rail Modular Installation
Communication System
Modicon TM5 Distributed I/O
Operating Temperature
-10...55°C
Storage Temperature
-25...70°C
Dimensions (W × H × D)
Approx. 12.5 × 90 × 70 mm
Weight
Approx. 20 g
Recommended Companion Models
Model
Product Name
TM5NS31
Schneider Modicon TM5 SERCOS III Interface Module
TM5NCO1
Schneider Modicon TM5 CANopen Interface Module
TM5SPS3
Schneider Modicon TM5 Fieldbus Interface Power Supply Module
TM5ACBM15
Schneider Modicon TM5 24 VDC Address Setting Bus Base Module
Frequently Selected Alternatives
Model
Product Name
TM5ACBN3
Schneider Modicon TM5 Fieldbus Interface Bus Base Module
TM5ACBM11
Schneider Modicon TM5 24 VDC Electronic Module Bus Base Module
TM5ACBM05R
Schneider Modicon TM5 Address Setting Bus Base Module
TM5ACBM3FS
Schneider Modicon TM5 Safety Coded Bus Base Module
Where It Excels in Industrial Use
• Fieldbus Interface Expansion Systems
The TM5ACBN1 provides the connection foundation for Modicon TM5 fieldbus interface assemblies, allowing automation systems to integrate communication interfaces and interface power distribution modules within distributed I/O architectures.
• Distributed Automation Network Integration
Designed for Modicon M258, LMC058, and LMC078 controller platforms, the module supports the construction of remote I/O islands that require reliable fieldbus communication and organized power management.
• Industrial Communication Infrastructure
The TM5ACBN1 is suitable for machine automation applications using fieldbus interface modules such as SERCOS III and CANopen communication solutions, helping connect decentralized I/O systems with higher-level control networks.
• OEM Machine Control Cabinet Design
With a compact modular structure, the TM5ACBN1 simplifies cabinet installation by providing a dedicated bus base for communication modules while maintaining the flexible TM5 slice-based architecture.
Key Strengths at a Glance
• Dedicated Fieldbus Interface Bus Base
The TM5ACBN1 is specifically designed as a bus base for Modicon TM5 fieldbus interface modules and Interface Power Distribution Modules (IPDM), providing a stable connection platform for communication expansion.
• 24 VDC Interface Power Support
The module supports 24 VDC power distribution for fieldbus interface assemblies, helping maintain reliable operation in demanding industrial environments.
• Broad Communication Module Compatibility
The TM5ACBN1 supports compatible TM5 communication components including TM5NCO1 interface module, TM5NS31 interface module, and TM5SPS3 power supply module.
• Compact Modular TM5 Construction
The white-coded bus base integrates seamlessly into Modicon TM5 modular I/O systems, offering efficient installation, clear component identification, and simplified maintenance.
Technical FAQs
1. What type of module is the Schneider TM5ACBN1?
The Schneider TM5ACBN1 is a Modicon TM5 bus base module designed for fieldbus interface modules and interface power distribution components.
2. What is the primary function of the TM5ACBN1?
The TM5ACBN1 provides the mechanical mounting structure and electrical connection interface required for assembling TM5 fieldbus communication units.
3. Which controller platforms are compatible with the TM5ACBN1?
The TM5ACBN1 is compatible with Modicon M258, LMC058, and LMC078 controller platforms.
4. Which communication modules can be installed with the TM5ACBN1?
The TM5ACBN1 supports TM5NCO1 CANopen interface module and TM5NS31 SERCOS III interface module configurations.
5. Is the TM5ACBN1 an input or output module?
No. The TM5ACBN1 is a bus base component and does not directly process field input or output signals.
6. What voltage rating does the TM5ACBN1 support?
The TM5ACBN1 is designed for a 24 VDC power supply environment.
7. What color identification does the TM5ACBN1 use?
The TM5ACBN1 uses a white housing design for identification within the Modicon TM5 modular system.
8. Does the TM5ACBN1 require software configuration?
No. The TM5ACBN1 is a hardware bus base component and does not require independent software configuration.
9. What protective accessories are included with the TM5ACBN1?
The TM5ACBN1 is supplied with two protective plates for secure installation and system protection.
10. What mounting method is used for the TM5ACBN1?
The TM5ACBN1 is installed as part of a Modicon TM5 modular system mounted on a DIN rail inside industrial control cabinets.
