Introduction

The Schneider TM5ACLPR10 Bus Base Locking Plate is an essential accessory for Modicon TM5 modular I/O systems, providing reliable mechanical protection for the right side of TM5 bus base configurations. Designed to cover exposed bus contacts, it helps protect the system from electrostatic discharge risks while maintaining the durability and reliability expected in industrial automation environments.

Developed for OEM machine manufacturers, automation engineers, and control system integrators, the TM5ACLPR10 offers a simple yet effective solution for completing TM5 installations. Its compact structure and dedicated compatibility ensure improved system protection, easier maintenance, and enhanced reliability in demanding industrial applications.

Technical Specifications

Parameter	Specification
Brand	Schneider Electric
Model Number	TM5ACLPR10
Product Type	Bus Base Locking Plate
Product Range	Modicon TM5
Module Type	Right Bus Base Protection Accessory
Function	Protects Exposed Right-Side TM5 Bus Contacts
Compatible System	Modicon TM5 Modular I/O System
Compatible Platforms	Modicon M258 / LMC058 Systems
Accessory Type	Mechanical Protection Component
Installation Position	Right Side of TM5 Configuration
Package Quantity	10 Pieces
Material	Plastic
Protection Function	Electrostatic Discharge Protection
Mounting Type	Snap-On Installation
Protection Rating	IP20 System Environment
Operating Temperature	-10...55°C
Storage Temperature	-25...70°C
Dimensions (W × H × D)	Approx. 12.5 × 90 × 7 mm
Weight	Approx. 4 g

Recommended Companion Models

Model	Product Name
TM5ACLPL10	Schneider Modicon TM5 Left Bus Base Locking Plate
TM5ACADL100	Schneider Modicon TM5 Electronic Module Locking Clip
TM5ACTLC100	Schneider Modicon TM5 Locking Plain Text Cover Holder
TM5ACTCH100	Schneider Modicon TM5 Terminal Block Locking Clip

Frequently Selected Alternatives

Model	Product Name
TM5ACLPL10	Schneider Modicon TM5 Left Bus Base Locking Plate
TM5ACBM11	Schneider Modicon TM5 24 VDC Bus Base Module
TM5ACBM15	Schneider Modicon TM5 24 VDC Address Setting Bus Base Module
TM5ACBN1	Schneider Modicon TM5 Fieldbus Interface Bus Base Module

Where It Excels in Industrial Use

• TM5 Modular I/O System Protection
The TM5ACLPR10 is designed to protect the exposed right-side bus contacts of Modicon TM5 modular I/O configurations, helping maintain system integrity during installation and operation.

• Industrial Control Cabinet Assembly
The locking plate is suitable for automation cabinets using Modicon TM5 expansion systems, providing an essential mechanical protection solution for distributed I/O installations.

• Remote I/O Configuration Safety Enhancement
By covering exposed bus connections, the TM5ACLPR10 helps reduce the risk of electrostatic discharge affecting TM5 system components, supporting reliable long-term operation in industrial environments.

• OEM Machine Building Applications
The accessory is ideal for machine builders and system integrators using Modicon M258, LMC058, and related TM5 architectures where compact and reliable modular protection is required.

Key Strengths at a Glance

• Dedicated Right-Side Bus Protection
The TM5ACLPR10 is a right bus base locking plate specifically designed for Modicon TM5 bus base assemblies, ensuring proper protection of unused exposed contacts.

• Electrostatic Discharge Protection
The locking plate helps prevent potential damage caused by electrostatic discharge during installation, maintenance, and handling of TM5 modular components.

• Simple Mechanical Installation
The compact accessory can be mounted directly onto the right side of a TM5 configuration, providing a quick and efficient finishing solution for modular I/O assemblies.

• Packaged for Industrial Maintenance Needs
The TM5ACLPR10 is supplied as a set of 10 right-side bus base locking plates, making it suitable for OEM production environments and spare-part management.

Technical FAQs

1. What type of product is the Schneider TM5ACLPR10?
The Schneider TM5ACLPR10 is a Modicon TM5 right bus base locking plate accessory used for protecting exposed bus contacts.

2. What is the main function of the TM5ACLPR10?
The TM5ACLPR10 protects the right-side exposed contacts of TM5 bus bases and helps maintain safe installation conditions within a modular I/O configuration.

3. Is the TM5ACLPR10 an electronic module?
No. The TM5ACLPR10 is a mechanical protection accessory and does not perform signal processing or communication functions.

4. Which product family does the TM5ACLPR10 belong to?
The TM5ACLPR10 belongs to the Schneider Electric Modicon TM5 modular I/O accessory family.

5. Where should the TM5ACLPR10 be installed in a TM5 configuration?
The TM5ACLPR10 should be installed on the rightmost slice of a TM5 system configuration to protect the exposed right-side bus connection.

6. How many pieces are included in one TM5ACLPR10 package?
The TM5ACLPR10 is supplied as a package containing 10 right bus base locking plates.

7. What material is used for the TM5ACLPR10?
The TM5ACLPR10 is manufactured as a plastic mechanical protection component designed for TM5 modular assemblies.

8. Can the TM5ACLPR10 replace TM5ACLPL10?
No. The TM5ACLPR10 is designed for right-side protection, while TM5ACLPL10 is intended for left-side bus base protection.

9. Does the TM5ACLPR10 require software configuration?
No. The TM5ACLPR10 is a passive mechanical accessory and does not require programming or software settings.

10. Which Schneider systems use the TM5ACLPR10?
The TM5ACLPR10 is used with Modicon TM5 modular I/O systems, including configurations based on compatible M258 and LMC058 automation platforms.
