Schneider TSXDMZ28DT Discrete Solid-State I/O Base DC
Schneider TSXDMZ28DT Discrete Solid-State I/O Base DC
0.0
Points
Brand:Schneider PLC Item No.:TSXDMZ28DT Product Origin:France Product Dimensions:260 x 180 x 55 mm Product Weight:0.425 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
Product Introduction and Industrial Digital Control Expansion Solution
The Schneider TSXDMZ28DT Discrete Solid-State I/O Base DC is a professional automation component designed to enhance the digital control capability of Modicon TSX Micro PLC systems. It provides a reliable interface between PLC controllers and industrial field devices, enabling efficient monitoring and control of automated processes.
Modern industrial machines require accurate feedback from sensors and fast responses from control devices. Digital inputs collect operating information from field equipment, while digital outputs provide control signals to external devices. The TSXDMZ28DT integrates these functions into a single module, helping engineers build compact and efficient automation solutions.
The solid-state output design provides faster switching capability compared with mechanical relay solutions, making it suitable for applications involving frequent operations, high-speed production cycles, and demanding industrial environments.
The module is widely used in machine upgrades, production line automation, and industrial control projects where stable digital signal processing and dependable operation are essential.
For automation engineers and system integrators, the Schneider TSXDMZ28DT Discrete Solid-State I/O Base DC provides a practical solution for improving PLC flexibility, simplifying system design, and maintaining reliable industrial control performance.
Technical Specifications
Parameter
Description
Manufacturer
Schneider Electric
Model Number
TSXDMZ28DT
Product Type
Discrete Solid-State I/O Base DC
Product Series
Modicon TSX Micro
Module Function
Digital Input and Solid-State Output Control
Total I/O Points
28 Channels
Digital Input Channels
16 Inputs
Digital Output Channels
12 Outputs
Input Type
Digital DC Input
Input Voltage
24 VDC
Output Type
Solid-State DC Output
Output Voltage
24 VDC
Output Function
Transistor Switching Control
Application
PLC Digital Signal Processing and Equipment Control
Compatible System
Modicon TSX Micro PLC Platform
Mounting Method
PLC Rack Installation
Connection Type
Terminal Connector
Dimensions
260 × 180 × 55 mm
Weight
0.425 kg
Application Environment
Industrial Automation Systems
Recommended Related Models
Model
Product Type
Schneider TSXDMZ28DT
Discrete Solid-State I/O Base DC
Schneider TSXDMZ28DR
Logic Relay I/O Base
Schneider TSXDMZ28AR
Logic Relay I/O Base
Schneider TSXDMY28RFK
Discrete I/O Module
Schneider TSXDEY16A5
Discrete Input Module
Popular Related Models
Model
Product Type
Schneider BMXDDM16022
Mixed Digital I/O Module
Schneider BMXDDI1602
Digital Input Module
Schneider BMXDDO1602
Digital Output Module
Schneider BMXAMI0810
Analog Input Module
Schneider BMXAMO0210
Analog Output Module
Schneider BMXP342020
Modicon M340 CPU Module
Schneider TM3DM32R
Hybrid I/O Module
Schneider TM3DQ16RG
Digital Output Module
The Schneider TSXDMZ28DT Discrete Solid-State I/O Base DC is a reliable industrial automation component designed for fast digital signal processing and DC output control. With integrated I/O functionality, solid-state switching technology, and compatibility with Modicon TSX Micro PLC systems, it supports efficient machine automation, production line control, and industrial digital expansion applications.
Applications
The Schneider TSXDMZ28DT Discrete Solid-State I/O Base DC is a digital I/O expansion module designed for industrial automation systems that require fast signal response, reliable digital communication, and efficient equipment control. As part of the Modicon TSX Micro automation platform, this module combines digital input acquisition and solid-state DC output control, providing a compact and efficient solution for PLC-based automation applications.
The TSXDMZ28DT is designed to collect ON/OFF signals from industrial sensors, switches, and detection devices while controlling DC loads through solid-state outputs. Its integrated design helps reduce system complexity, simplify wiring, and improve the overall reliability of automation systems.
Compared with traditional relay output modules, solid-state outputs provide faster switching response and are better suited for applications requiring frequent switching operations, high-speed control, and long service life.
Typical application areas include:
Industry
Application
Machine Manufacturing
Automated equipment control, sensor monitoring, and production machinery
Packaging Industry
Conveyor systems, product detection, and process control
Automotive Manufacturing
Assembly equipment monitoring and component positioning
Material Handling
Transport systems, position detection, and actuator control
Factory Automation
Digital signal collection and high-speed device control
The Schneider TSXDMZ28DT Discrete Solid-State I/O Base DC provides a reliable solution for industrial users requiring compact PLC expansion, fast switching performance, and stable digital control.
Solid-State Digital I/O Advantages and Industrial Benefits
Integrated Digital Input and Output Functions
The TSXDMZ28DT combines digital input monitoring and solid-state output control in one module, reducing the need for multiple separate I/O components and improving automation system efficiency.
Fast Switching Performance
Solid-state outputs provide rapid response and are suitable for machines that require frequent switching cycles, precise timing control, and continuous operation.
Reliable Sensor Compatibility
The module supports connection with various industrial digital devices, including proximity sensors, limit switches, push buttons, and detection equipment.
Improved System Reliability
Solid-state output technology reduces mechanical wear compared with traditional relay switching, helping improve long-term operational stability.
Space-Saving Automation Design
The integrated I/O structure helps engineers optimize control cabinet layouts and reduce installation complexity.
Efficient Troubleshooting and Maintenance
A centralized I/O design makes signal monitoring, fault diagnosis, and maintenance activities easier for technicians.
Technical FAQs
Q1: What is the main function of the Schneider TSXDMZ28DT?
A: The TSXDMZ28DT is a discrete solid-state I/O base module used for collecting digital input signals and controlling DC output devices in PLC automation systems.
Q2: What type of devices can be connected to the TSXDMZ28DT?
A: It can connect with digital field devices such as proximity sensors, limit switches, push buttons, indicators, and DC-controlled actuators.
Q3: Why use solid-state outputs in industrial automation?
A: Solid-state outputs provide faster switching speed, longer service life, and better performance for applications with frequent ON/OFF operations.
Q4: What causes digital input signal failures?
A: Common causes include incorrect wiring, damaged sensors, unstable power supply, cable problems, signal interference, or incorrect PLC configuration.
Q5: How can technicians troubleshoot output problems?
A: Check PLC logic, output status indicators, wiring connections, load conditions, and module diagnostic information.
Q6: Can the TSXDMZ28DT control industrial equipment?
A: Yes, it can control compatible DC loads such as indicators, solenoid devices, and industrial control components within the module specifications.
Q7: What happens if the output load exceeds the rated value?
A: Excessive load conditions may cause output protection activation, abnormal operation, or possible module damage.
Q8: How does electrical interference affect digital I/O signals?
A: Strong electrical noise may cause unstable signal detection, false triggering, or incorrect equipment responses.
Q9: What maintenance is recommended for this module?
A: Regular maintenance should include checking terminal connections, field wiring, sensor operation, output loads, and PLC diagnostic information.
Q10: How does the TSXDMZ28DT improve automation performance?
A: It expands PLC digital control capability while providing fast and reliable signal processing for industrial applications.
