Brand:Emerson Module Item No.:VE4002S2T2B1 Product Origin:USA Product Dimensions:110 × 66.8 × 50 mm Product Weight:0.30 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Emerson VE4002S2T2B1 Discrete Output Module is a high-performance DeltaV M-Series I/O component designed to provide reliable 115/230 VAC high-side discrete output control in industrial automation environments. As part of the DeltaV traditional I/O family, it delivers consistent signal switching performance for applications where operational stability and system availability are essential.
Engineered for demanding process industries, the VE4002S2T2B1 helps improve control system efficiency through flexible integration, dependable field connectivity, and proven DeltaV platform compatibility. It is a practical solution for plant expansions, system upgrades, and long-term automation maintenance projects.
Technical Specifications
Specification
Details
Manufacturer
Emerson
Model
VE4002S2T2B1
Module Type
Discrete Output Module
System Platform
Emerson DeltaV M-Series
Output Type
High-Side Discrete Output
Number of Channels
8 Channels
Output Voltage
115/230 VAC
Termination Type
Standard I/O Termination Block
Application
Industrial Process Control
Configuration Method
DeltaV Engineering Software
Operating Temperature
-40°C to +70°C
Dimensions
Approx. 120 × 50 × 110 mm
Weight
Approx. 0.35 kg
Recommended Companion Models
Model
Product Name
VE4002S2T2B2
DeltaV Discrete Output Card, 8 Channels 115/230 VAC High Side with Fused I/O Termination Block
VE4002S2T1B1
DeltaV Discrete Output Card, 8 Channels 115/230 VAC Isolated with Standard I/O Termination Block
VE4002S1T2B1
DeltaV Discrete Output Card, 8 Channels 24 VDC High Side with Standard I/O Termination Block
VE4032S1T2B1
DeltaV Redundant Discrete Output Card, 8 Channels 24 VDC High Side
DeltaV Discrete Output Card, 8 Channels 24 VDC High Side with Fused I/O Termination Block
VE4002S2T2B8
DeltaV Discrete Output Terminal Block, 32 Channels Series 2 Plus
Where It Excels in Industrial Use
• Designed for Emerson DeltaV M-Series distributed control systems requiring reliable 115/230 VAC discrete output control for industrial field equipment.
• Suitable for process automation applications including oil and gas, chemical processing, power generation, and manufacturing plants where stable digital switching performance is required.
• Ideal for controlling AC-powered devices such as valves, relays, alarms, and actuators within DeltaV control architectures requiring dependable output signal management.
Key Strengths at a Glance
• Provides 8-channel 115/230 VAC high-side discrete output capability for efficient field device control.
• Integrates seamlessly with Emerson DeltaV M-Series traditional I/O systems for simplified engineering and maintenance operations.
• Supports stable switching performance for critical industrial applications requiring continuous and reliable operation.
• Uses modular DeltaV I/O architecture to improve system flexibility, troubleshooting efficiency, and lifecycle management.
Technical FAQs
1. What type of module is the Emerson VE4002S2T2B1?
The Emerson VE4002S2T2B1 is a DeltaV discrete output card designed for 8-channel 115/230 VAC high-side output applications.
2. Which control system platform is compatible with the VE4002S2T2B1?
The VE4002S2T2B1 is designed for Emerson DeltaV M-Series traditional I/O systems and compatible DeltaV hardware configurations.
3. How many output channels does this discrete output module provide?
The module provides 8 discrete output channels for controlling compatible AC field devices in industrial automation environments.
4. What output voltage does the VE4002S2T2B1 support?
The module supports 115/230 VAC discrete output operation for industrial control applications.
5. What types of field devices can be controlled by this module?
The module can control compatible discrete devices such as actuators, alarms, motor starters, and other AC-operated industrial equipment.
6. What is the difference between high-side and isolated output designs?
High-side output switching controls the positive side of the power supply path, while isolated output designs provide electrical separation between channels and field circuits.
7. How is the VE4002S2T2B1 configured in a DeltaV system?
The module is configured through DeltaV engineering tools by assigning hardware parameters, channel settings, and I/O functions according to system requirements.
8. Can the VE4002S2T2B1 be used in existing DeltaV installations?
Yes, the module can be integrated into compatible DeltaV M-Series systems where the required I/O carrier and termination configuration are available.
9. What maintenance advantages does this module provide?
The module supports standardized DeltaV diagnostics and modular replacement methods, helping engineers reduce troubleshooting time and simplify system maintenance.
10. What applications commonly use this type of discrete output module?
This type of module is commonly used in process control systems requiring dependable ON/OFF control of AC field equipment.
