Allen Bradley 1783-BMS06SGA Managed Ethernet Switch Module
Allen Bradley 1783-BMS06SGA Managed Ethernet Switch Module
0.0
Points
Brand:Allen Bradley PLC Item No.:1783-BMS06SGA Product Origin:USA Product Dimensions:129.5 × 74.8 × 116.7 mm Product Weight:1.11 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 1783-BMS06SGA Managed Ethernet Switch Module is part of the Stratix 5700 industrial networking family, providing a compact and reliable communication solution for automation systems. With four copper Ethernet ports and two Gigabit SFP fiber ports, it supports flexible network designs for industrial control environments.
Designed for demanding automation applications, the 1783-BMS06SGA combines industrial-grade construction with managed switching capabilities. It helps engineers improve network organization, simplify diagnostics, and maintain stable communication between controllers, I/O devices, and Ethernet-enabled equipment.
Technical Specifications
Specification
Details
Manufacturer
Allen Bradley / Rockwell Automation
Model
1783-BMS06SGA
Product Family
Stratix 5700
Module Type
Managed Ethernet Switch Module
Total Ports
6 Ports
Copper Ethernet Ports
4 × 10/100 Mbps RJ45
Fiber Ports
2 × 10/100/1000 Mbps SFP
Firmware Type
Full
Network Type
Industrial Ethernet
Management Capability
Managed Switch
Layer 2 Capability
Yes
Layer 3 Capability
No
Mounting Method
DIN Rail Mount
Input Voltage
12–48V DC
Maximum Power Consumption
15 W
Power Consumption at 24V DC
Approx. 9.5 W
Protection Rating
IP30
Dimensions
Approx. 129.5 × 74.8 × 116.7 mm
Weight
Approx. 1.11 kg
Recommended Companion Models
Model
Product Name
1783-BMS06SGP
Allen Bradley Stratix 5700 6-Port Managed Ethernet Switch with PoE Capability
1783-BMS10CGN
Allen Bradley Stratix 5700 10-Port Managed Ethernet Switch
1783-BMS20CGN
Allen Bradley Stratix 5700 20-Port Managed Ethernet Switch
1783-BMS12T4E2CGN
Allen Bradley Stratix 5700 Managed Ethernet Switch
Frequently Selected Alternatives
Model
Product Name
1783-CMS6P
Allen Bradley Stratix 5200 6-Port Managed Ethernet Switch
1783-BMS06SGL
Allen Bradley Stratix 5700 6-Port Managed Ethernet Switch Lite Firmware Version
1783-BMS06SA
Allen Bradley Stratix 5700 6-Port Managed Ethernet Switch
1783-ETAP2F
Allen Bradley EtherNet/IP Tap Module with Fiber Connectivity
Where It Excels in Industrial Use
• Designed for Allen Bradley Stratix 5700 industrial Ethernet networks requiring dependable managed switching, flexible connectivity, and efficient automation communication.
• Suitable for manufacturing automation, machine control systems, process industries, and distributed control environments where reliable EtherNet/IP networking is essential.
• Ideal for compact control cabinets that require both copper Ethernet connections and fiber uplink capability for industrial network expansion.
Key Strengths at a Glance
• Provides six managed Ethernet ports, including four 10/100 Mbps RJ45 copper ports and two Gigabit SFP fiber ports for flexible network layouts.
• Uses full firmware functionality to support advanced switch management, diagnostics, and industrial network configuration.
• Supports DIN rail mounting and industrial 12–48V DC power input, making it suitable for automation panels and harsh industrial environments.
• Helps improve network visibility and troubleshooting efficiency through managed Ethernet capabilities within Allen Bradley Integrated Architecture systems.
Technical FAQs
1. What type of device is the Allen Bradley 1783-BMS06SGA?
The Allen Bradley 1783-BMS06SGA is a Stratix 5700 managed industrial Ethernet switch designed for industrial automation communication networks.
2. How many ports does the 1783-BMS06SGA provide?
The switch provides six Ethernet ports, including four 10/100 Mbps RJ45 copper ports and two 10/100/1000 Mbps SFP ports.
3. Does the 1783-BMS06SGA support EtherNet/IP networks?
Yes, the switch is designed for industrial Ethernet applications commonly used with Allen Bradley controllers, remote I/O modules, drives, and automation devices.
4. What firmware type does the 1783-BMS06SGA use?
The 1783-BMS06SGA uses full firmware, providing enhanced management and configuration capabilities compared with Lite firmware versions.
5. What communication interfaces are available on the 1783-BMS06SGA?
The module provides four copper Ethernet ports and two Gigabit SFP fiber ports for industrial network communication.
6. Does the 1783-BMS06SGA require network configuration?
Yes, as a managed Ethernet switch, it requires configuration for IP addressing, port settings, and network management functions.
7. What type of mounting method is used for this switch?
The 1783-BMS06SGA is designed for DIN rail (top hat rail) mounting in industrial control cabinets.
8. What power supply does the 1783-BMS06SGA require?
The switch operates from a 12–48V DC industrial power supply suitable for automation installations.
9. Can the 1783-BMS06SGA be integrated into existing Stratix networks?
Yes, it can be integrated into compatible Allen Bradley Stratix 5700 Ethernet architectures for network expansion or replacement applications.
10. What applications commonly use the 1783-BMS06SGA?
The switch is commonly used in factory automation, production lines, remote I/O communication systems, and industrial Ethernet infrastructures.
