Allen Bradley 1783-SFP1GSX Fiber Optic SFP Transceiver Module
Allen Bradley 1783-SFP1GSX Fiber Optic SFP Transceiver Module
0.0
Points
Brand:Allen Bradley PLC Item No.:1783-SFP1GSX Product Origin:USA Product Dimensions:13.4 × 56.5 × 8.5 mm Product Weight:15 g Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 1783-SFP1GSX Fiber Optic SFP Transceiver Module is a Gigabit Ethernet optical communication component designed for use with compatible industrial Ethernet switching platforms. Supporting 1000BASE-SX multimode fiber communication, it provides a reliable solution for extending Ethernet networks beyond the limitations of copper cabling.
Engineered for industrial automation environments, the 1783-SFP1GSX helps improve network design flexibility by enabling fiber-based connections between switches and distributed automation equipment. Its compact SFP format, high-speed communication capability, and compatibility with Allen Bradley networking products make it a practical choice for industrial Ethernet expansion and modernization projects.
Technical Specifications
Specification
Details
Manufacturer
Allen Bradley / Rockwell Automation
Model
1783-SFP1GSX
Module Type
Fiber Optic SFP Transceiver Module
Product Family
Stratix Industrial Networking
Fiber Standard
1000BASE-SX
Data Rate
1 Gbps
Fiber Type
Multimode Fiber (MMF)
Connector Type
Dual LC
Wavelength
850 nm
Core / Cladding Size
62.5/125 μm or 50/125 μm
Maximum Distance
Up to 550 m (depending on fiber type)
Installation Type
SFP Slot Installation
Operating Voltage
3.3 V
Power Consumption
Approx. 0.8 W
Operating Temperature
0°C to 70°C
Dimensions
Approx. 13.4 × 56.5 × 8.5 mm
Weight
Approx. 15 g
Recommended Companion Models
Model
Product Name
1783-SFP1GLX
Allen Bradley Stratix 1000BASE-LX Single-Mode Fiber SFP Transceiver
1783-SFP1GTE
Allen Bradley Stratix 1000BASE-T Copper SFP Transceiver
1783-BMS06SGA
Allen Bradley Stratix 5700 6-Port Managed Ethernet Switch
1783-BMS10CGN
Allen Bradley Stratix 5700 10-Port Managed Ethernet Switch
Frequently Selected Alternatives
Model
Product Name
1783-SFP1GSX-C
Allen Bradley Compatible 1000BASE-SX Multimode Fiber SFP Transceiver
1783-SFP1GLX-C
Allen Bradley Compatible 1000BASE-LX Single-Mode Fiber SFP Transceiver
1783-ETAP2F
Allen Bradley EtherNet/IP Tap Module with Fiber Connectivity
1783-BMS20CGN
Allen Bradley Stratix 5700 20-Port Managed Ethernet Switch
Where It Excels in Industrial Use
• Designed for Allen Bradley Stratix industrial Ethernet switches requiring reliable Gigabit fiber communication and extended network connectivity in automation environments.
• Suitable for factory automation, process control, manufacturing networks, and industrial communication systems where fiber-based Ethernet links are required for improved distance and noise immunity.
• Ideal for connecting Stratix managed switches and other compatible industrial networking equipment through multimode fiber infrastructure, supporting stable high-speed data transmission.
Key Strengths at a Glance
• Provides 1000BASE-SX Gigabit Ethernet optical communication through a compact SFP transceiver design.
• Supports multimode fiber connections with an 850 nm wavelength and dual LC fiber connector interface for efficient network integration.
• Enables longer-distance industrial Ethernet communication compared with standard copper connections, helping improve network flexibility and installation efficiency.
• Features a hot-pluggable SFP form factor, allowing convenient installation and replacement within compatible Ethernet switch platforms.
Technical FAQs
1. What type of device is the Allen Bradley 1783-SFP1GSX?
The Allen Bradley 1783-SFP1GSX is a 1000BASE-SX multimode fiber SFP transceiver module designed for industrial Ethernet networking applications.
2. What is the main function of the 1783-SFP1GSX?
The module converts electrical Gigabit Ethernet signals from an SFP-compatible switch port into optical signals for transmission through multimode fiber cables.
3. What fiber type does the 1783-SFP1GSX support?
The 1783-SFP1GSX supports multimode fiber (MMF) communication using 850 nm optical transmission.
4. What connector type is used on the 1783-SFP1GSX?
The module uses a dual LC fiber optic connector interface for transmit and receive optical communication.
5. What Ethernet speed does the 1783-SFP1GSX support?
The module supports Gigabit Ethernet communication with a data rate of 1000 Mbps.
6. Which Allen Bradley products are compatible with the 1783-SFP1GSX?
The module is designed for use with compatible Allen Bradley Stratix industrial Ethernet switches and networking equipment that support 1G fiber SFP modules.
7. What is the maximum transmission distance of the 1783-SFP1GSX?
The maximum distance depends on fiber type and bandwidth. It can support up to 550 m using suitable 50/125 μm multimode fiber.
8. Does the 1783-SFP1GSX require software configuration?
No, the SFP module itself does not require programming. Network configuration is handled by the connected Ethernet switch or network device.
9. What applications commonly use the 1783-SFP1GSX?
It is commonly used in industrial Ethernet backbone connections, switch uplinks, control networks, and automation communication systems requiring fiber connectivity.
10. What are the maintenance advantages of the 1783-SFP1GSX?
The plug-in design allows fast replacement, simplified network maintenance, and efficient troubleshooting of industrial fiber communication links.
