Allen Bradley 1783-SFP1GLX Fiber Optic SFP Transceiver Module
Allen Bradley 1783-SFP1GLX Fiber Optic SFP Transceiver Module
0.0
Points
Brand:Allen Bradley PLC Item No.:1783-SFP1GLX Product Origin:USA Product Dimensions:13.4 × 56.5 × 8.5 mm Product Weight:0.03 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 1783-SFP1GLX Fiber Optic SFP Transceiver Module is a Gigabit Ethernet optical communication component designed for Stratix industrial networking platforms. Supporting 1000BASE-LX/LH single-mode fiber communication, it provides a reliable solution for extending Ethernet connections over long distances while maintaining stable industrial data transmission.
Engineered for demanding automation environments, the 1783-SFP1GLX helps optimize industrial network architecture by enabling fiber-based connections between Ethernet switches, control systems, and distributed automation equipment. Its compact design, long-distance capability, and industrial compatibility make it a practical choice for network expansion and modernization projects.
Technical Specifications
Specification
Details
Manufacturer
Allen Bradley / Rockwell Automation
Model
1783-SFP1GLX
Module Type
Fiber Optic SFP Transceiver Module
Product Family
Stratix Industrial Networking
Fiber Standard
1000BASE-LX/LH
Data Rate
1 Gbps
Fiber Type
Single-Mode Fiber (SMF)
Connector Type
Dual LC
Wavelength
1310 nm
Maximum Transmission Distance
Up to 10 km
Fiber Core Type
G.652 Single-Mode Fiber
Digital Optical Monitoring
Supported
Installation Type
SFP Slot Installation
Operating Voltage
3.3 V DC
Power Consumption
Approx. 0.8 W
Operating Temperature
-40°C to +85°C
Dimensions
Approx. 13.4 × 56.5 × 8.5 mm
Weight
Approx. 0.03 kg
Recommended Companion Models
Model
Product Name
1783-SFP1GSX
Allen Bradley Stratix 1000BASE-SX Multimode Fiber SFP Transceiver Module
1783-SFP1GTE
Allen Bradley Stratix 1000BASE-T Copper SFP Transceiver Module
1783-BMS06SGA
Allen Bradley Stratix 5700 6-Port Managed Ethernet Switch Module
1783-BMS10CGN
Allen Bradley Stratix 5700 10-Port Managed Ethernet Switch Module
Frequently Selected Alternatives
Model
Product Name
1783-SFP1GLX-C
Allen Bradley Compatible 1000BASE-LX Single-Mode Fiber SFP Transceiver
1783-SFP1GSX-C
Allen Bradley Compatible 1000BASE-SX Multimode Fiber SFP Transceiver
1783-BMS20CGN
Allen Bradley Stratix 5700 20-Port Managed Ethernet Switch Module
1783-ETAP2F
Allen Bradley EtherNet/IP Tap Module with Fiber Connectivity
Where It Excels in Industrial Use
• Designed for Allen Bradley Stratix industrial Ethernet networks requiring high-performance Gigabit fiber communication and extended-distance data transmission.
• Suitable for manufacturing automation, process control, power generation, and industrial communication systems where fiber optic connections provide improved noise immunity and reliable network performance.
• Ideal for connecting Stratix managed switches through single-mode fiber infrastructure, supporting stable Ethernet backbone links across large industrial facilities.
Key Strengths at a Glance
• Provides 1000BASE-LX/LH Gigabit Ethernet optical communication through a compact SFP transceiver design.
• Supports single-mode fiber transmission using a 1310 nm wavelength with communication distances up to 10 km.
• Features a dual LC connector interface and hot-swappable SFP format for convenient installation and maintenance.
• Includes Digital Optical Monitoring (DOM) capability for improved visibility of fiber link operating conditions.
Technical FAQs
1. What type of device is the Allen Bradley 1783-SFP1GLX?
The Allen Bradley 1783-SFP1GLX is a Gigabit Ethernet SFP fiber optic transceiver module designed for industrial networking applications.
2. What is the primary function of the 1783-SFP1GLX?
The module converts electrical Gigabit Ethernet signals from compatible switch SFP ports into optical signals for transmission over single-mode fiber cables.
3. What fiber type does the 1783-SFP1GLX support?
The 1783-SFP1GLX supports single-mode fiber (SMF) communication using 1000BASE-LX/LH technology.
4. What wavelength does the 1783-SFP1GLX use?
The module operates at a 1310 nm optical wavelength for Gigabit fiber communication.
5. What is the maximum transmission distance of the 1783-SFP1GLX?
The module supports fiber transmission distances up to 10 km when used with suitable single-mode fiber cabling.
6. Which Allen Bradley products are compatible with the 1783-SFP1GLX?
The module is designed for compatible Stratix industrial Ethernet switches that support Gigabit SFP interfaces.
7. Does the 1783-SFP1GLX require software configuration?
No, the SFP transceiver itself does not require programming. Network settings are managed by the connected Ethernet switch.
8. What connector type is used on the 1783-SFP1GLX?
The module uses a dual LC fiber optic connector interface for transmit and receive communication.
9. What industrial applications commonly use the 1783-SFP1GLX?
It is commonly used in industrial Ethernet backbone links, switch-to-switch connections, remote automation networks, and large-scale control system installations.
10. What maintenance advantages does the 1783-SFP1GLX provide?
The pluggable SFP design allows quick replacement, simplified troubleshooting, and efficient maintenance of industrial fiber communication networks.
