Brand:Allen Bradley PLC Item No.:TM258LD42DT4L Product Origin:France Product Dimensions:161.5 × 125 × 76 mm Product Weight:0.48 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM258LD42DT4L Logic Controller Module is part of the Modicon M258 controller family, developed for flexible machine automation applications requiring dependable processing performance and integrated I/O capability. With embedded digital and analog resources, Ethernet connectivity, and expansion support, it provides an efficient control platform for modern industrial machines.
Designed for manufacturers seeking reliable automation solutions, the TM258LD42DT4L combines compact hardware design with powerful programming flexibility. Its compatibility with EcoStruxure Machine Expert and Modicon TM5 expansion modules makes it suitable for scalable machine architectures ranging from simple equipment control to more advanced automation systems.
Technical Specifications
Specification
Details
Manufacturer
Schneider Electric
Model
TM258LD42DT4L
Product Family
Modicon M258
Module Type
Logic Controller Module
Power Supply
24V DC
Embedded I/O
42 Digital I/O + 4 Analog Inputs
Digital Inputs
12
Digital Outputs
12
Analog Inputs
4
Ethernet Interface
1 Port
Serial Line Interface
1 Port
USB Programming Port
Supported
PCI Expansion
2 Slots
Programming Software
EcoStruxure Machine Expert
Expansion System
Modicon TM5 I/O
Application
Machine Automation Control
Mounting Method
DIN Rail Mount
Dimensions
Approx. 161.5 × 125 × 76 mm
Weight
Approx. 0.48 kg
Recommended Companion Models
Model
Product Name
TM258LF42DT4L
Schneider Modicon M258 Logic Controller with CANopen and Analog I/O
Schneider Modicon M251 Logic Controller with Ethernet
TM262L01MESE8T
Schneider Modicon M262 Logic/Motion Controller
TM241CEC24T
Schneider Modicon M241 Logic Controller
BMXP342020
Schneider Modicon M340 Processor Module
Where It Excels in Industrial Use
• Designed for Schneider Electric Modicon M258 machine automation platforms requiring reliable logic processing, embedded I/O control, and flexible communication capabilities.
• Suitable for packaging machinery, conveying systems, material handling equipment, and general machine control applications where compact PLC performance and scalable I/O expansion are required.
• Ideal for industrial automation projects that require integration with Modicon TM5 modular I/O systems, Ethernet communication, and EcoStruxure Machine Expert programming environments.
Key Strengths at a Glance
• Provides a compact PLC solution with 42 embedded I/O points plus 4 analog inputs for efficient machine control applications.
• Integrates Ethernet, serial communication, USB programming interface, and PCI expansion capability for flexible system connectivity.
• Supports high-speed counting, reflex outputs, and event-driven task processing for demanding automation sequences.
• Works with EcoStruxure Machine Expert software, providing a unified engineering environment for programming, commissioning, and maintenance.
